It applicable the crushing strength of not more than 200 Mpa of limestone, gypsum, coal, marl, sand shale, with broken than ...Sell Hammer Crusher
Mr. Sunny
Skype: sunnyhaifeng
Cell: +86 138 6271 7731
PCF Series Single-stage Hammer Crusher applicable the crushing strength of not more than 200 Mpa of limestone, gypsum, coal, marl, sand shale, with broken than large, uniform product size, structure simple, reliable, easy maintenance , operating costs and economic characteristics, widely used in the cement industry.
Main technical parameters
Model | Inlet Size mm | Discharge size mm | Max. Feed Size mm | Rotor Diameter mm | Rotor Length mm | Capacity t/h | Power kw | Weight (Excluding motor) t |
PCF-1412 | 1290x1320 | ≤25 | 600x600x900 | 1420 | 1200 | 80-130 | 130-190 | 23.5 |
PCF-1616 | 1500x1785 | ≤25 | 800x800x1000 | 1650 | 1630 | 130-240 | 250-350 | 43.3 |
PCF-1818 | 1750x1840 | ≤25 | 900x900x1200 | 1850 | 1730 | 240-350 | 400-560 | 70 |
PCF-2018 | 2268x2130 | ≤25 | 1000x1000x1000 | 2020 | 1820 | 350-450 | 630-710 | 89 |
PCF-2022 | 2100x2380 | ≤25 | 1000x1000x1500 | 2020 | 2230 | 400-600 | 630-800 | 128 |
Annotate: The throughput capacity figures apply to pure medium-hard limestone
