The equipment is applicable to concentrate , the alcohol recycle and cream recycle of the industries
The equipment is applicable to the alcohol recycle and cream recycle of the industries such as pharnacy plants,starch,chemical industry,foodstuff and dairy products,and it can be used in liquid concentration of small quantity and various materials.
1.Alcohol recycling: It has strong recycling capacity,adopts vacuum operation way and improved the workmanship procedure of the equipment.The production ratio has been improved by 5 to 10 times compared with old types of the hoogeneous equipments, and the recycling ratio can reach up to above95%.The consumption of alcohol is less than5%.and then it decreases the consumption by30%. It is a kind of energy-save equipment of small investment and high recycling profit.
2.After the alcohol is recycled.the equipment adopts the way of extemal heating nature circulation and vacuum positive pressure
evaporation with rapid vapor speed and large gravity of concentration.The liquid is concentrated in the full hermetic and non-bubble
state.
3.It does not need to process in the Heater wnen recycling cream close the upper and lower butterfly valves off the Herter, the recycling of cream can be processed at the botton of the Heater,an the gravity can reach up to above1.35.
Main Technique Parameter
model |
WZB-500 |
WZB-1000 |
WZB-1500 |
WZB-2000 |
||
cost steam kg/h |
575 |
1150 |
1725 |
2300 |
||
evaporation capacity kg/h |
500 |
1000 |
1500 |
2000 |
||
cost water T/h |
10 |
18 |
25 |
36 |
||
vacuum degree MPa |
0.08 |
0.08 |
0.08 |
0.08 |
||
steam pressure Mpa |
0.09 |
0.09 |
0.09 |
0.09 |
||
dimensionmm |
3050*800*3850 |
3700*1050*4500 |
4250*1250*5600 |
3500*1400*3800 |
||
