Use: This equipment is suitable for mixing, concentrating and decocting the material in pharmacetucial, foodstuff and chemical industry etc.
Summarize: This equipment is consist of pan, plank,worm wheel and worm.The pan can turn within 180°, so it is easy for taking out the material. The equipment can configure the mixing system according to different craft demand.We have steam heating and electric heating can be choosen.
Main technical parameter:
Technical Parameter/Model |
50L |
100L |
150L |
200L |
300L |
400L |
500L |
Volume(L) |
50 |
100 |
150 |
200 |
300 |
400 |
500 |
Pressure of jacekt(Mpa) |
<0.1 |
||||||
Evaporation capacity(kg/h) |
32 |
50 |
55 |
73 |
89 |
110 |
127 |
Heating area(m2) |
0.48 |
0.77 |
0.82 |
1.1 |
1.33 |
1.67 |
1.90 |
Energy consumption(kg/h) |
37 |
60 |
64 |
84 |
100 |
130 |
145 |
Dimension(m) |
1*0.6*1.2 |
1.2*0.7*1.3 |
1.3*0.8*1.3 |
1.3*0.9*1.3 |
1.5*1*1.4 |
1.6*1.1*1.4 |
1.7*1.2*1.6 |
Note:
We also could do produce according to your requirment!
Gas burner or external insulation,ect.
