Specifications
plastic blow moulding machine ZK-90Bimport PLC,touch screen,valve
barrel,toolbox,model,automobile,drum
PE,PP,ABS,PA
max 60L
plastic blow moulding machine ZK-90B (extrusion blow molding machine)----for plastic mannequine
This model adopts fixed mould open-closing system and accumulator die. Parison programmer is available to control thickness. This model is automatic process with low noise, saving energy, high efficiency, safe operation, easy maintenance and other benefits. This model is widely used to produce chemical barrel, auto parts(water box, oil box, air-condition pipe, auto tail), toys(wheel, hollow auto bike, basketball stands, baby castle), tool box, vacuum cleaner pipe, chairs for bus and gymnasium, etc. This model can produce max 50L hollow plastic product.
PE.PP.HDPE.ABS,PS,PA,EVA etc material
Variety of functions for different products matching the technological requirements: bottom blow and lift, rotation, encapsulation, material support, sub-mould, robot, parison control system ,etc.
following is the technical specifications of extrusion blow molding machine ZK-90B:
specification |
unit |
zk-90A |
zk-90B |
max container capacity |
L |
50 |
60 |
number of die heads |
set |
1 |
1 |
machine dimension(L*W*H) |
M |
5*3.1*3.2 |
5*3.1*3.9 |
total weight |
ton |
7 |
9 |
clamping unit |
|
|
|
clamping force |
KN |
300 |
300 |
platen opening stroke |
mm |
350-1050 |
350-1050 |
max mould size(W*H) |
mm |
700*1000 |
700*1000 |
mould thickness |
mm |
360-500 |
360-500 |
power |
|
|
|
max drive |
KW |
11 |
11 |
total power |
KW |
63 |
70 |
fan power for screw |
KW |
0.9 |
0.72 |
air pressure |
Mpa |
0.7 |
0.7 |
air consumption |
m3/min |
0.9 |
0.9 |
average energy consumption |
KW |
28 |
35 |
extruder unit |
|
|
|
screw diameter |
mm |
90 |
90 |
screw L/D ratio |
L/D |
25:1 |
25:1 |
plasticizing capacity |
kg/hr |
100 |
120 |
number of heating zone |
zone |
5 |
4 |
extruder heating power |
KW |
12.5 |
12.5 |
extruder driving power |
KW |
22 |
30 |
accumulator head |
|
|
|
die head dimension |
m |
|
|
number of heating zone |
zone |
3 |
5 |
power of die heating |
KW |
7 |
20 |
max die-pin diameter |
mm |
350 |
350 |
accumulator volume |
L |
5 |
6 |
more information, contact me!
