Emulsification Equipment is to blend the materials efficient under mixing pressing and cutting by the high-speed rotation of the impeller in the bottom, which is especially applicable for the mixture of sugar, starch, milk powder, egg power products with emulsifying agent, stabilizing agent and thickening agent, usually used in the mixing flow of formula milk power, acidophilus milk, various drinks, ice cream, egg roll and waffles. We have adopted R-arc transition regarding the structural design to guarantee there is no dead corner to influence the sanitation; Furthermore, the technical innovation has been carried out on the sealing structure for the mixing at the bottom to prolong the service life of the mechanic seal and bearing to the largest extent, and it has also saved the service cost for the clients.
Tank body
Volume: 50L~10, 000L and even larger
Material: Ss304 or ss316(manufacture according to you)
Insolation material: High quality Polyurethan from Japan
Jacket: Whole jacket, coil jacket, dimple plate jacket
Configuration
Configuration of tank:
1) Manhole
2) CIP cleaner
3) Adjustable triangle bracket
4) Ladder
5) Thermometer
6) Liquid lever meter and controller
7) Eddy-proof board
8) Dismountable Inlet assembly
9) Sanitary breathing cover
10) Mixer
11) Three-layer, PU insulated dual-layer, jacketed dual-layer or single-layer (according to you)
12) Motor: ABB, Siemens, SEW( we always choose ABB)
13) Inverter
P. S. Customers can choose their suitable configurations. We will manufacture according to your requirement.
| working volume (L) |
length of internal tank (mm) |
width of inner tank (mm) |
height of internal tank (mm) |
total preservation (mm) |
| 400 | 900 | 900 | 550 | 1,700 |
| 800 | 1,050 | 1,050 | 750 | 1,950 |
| 1,000 | 1,150 | 1,150 | 750 | 2,000 |
| 1,500 | 1,250 | 1,250 | 1,000 | 2,300 |
| working volume (L) |
heat preservation layer (mm) |
motor power (kw) |
rotation speed (r/min) |
|
| 400 | 50 | 7.5 | 1460 | |
| 800 | 50 | 15 | 1460 | |
| 1,000 | 50 | 15 | 1460 | |
| 1,500 | 50 | 18.5 | 1460 |
