Home > Products > Forklift Trucks > CPD25 Battery Powered Forklift Trucks
CPD25 Battery Powered Forklift Trucks
Negotiable
/ Set
4 Sets(Min.Order)
- 100 Set / Sets per Month
- T/T
You May Like
Product Details
| Condition | New | Place of Origin | Guangxi, China | |
| Brand Name | LIUGONG | Model Number | CPD25 Battery Powered Forklift Trucks | |
| Type | Manual Pallet Truck | Power Souce | Diesel Engine | |
| Rated Loading Capacity | 2.5ton |
Product Description
Specifications
Electric forklift is for the place with high environment requirement, such as stations, factories and mines and warehouses.
Dimensions
Electromotor
Track
Tyre
| Length | 3425mm | |
| Width | 1150mm | |
| Mast lowered height | 2040mm | |
| Mast extended height | 4000mm | |
| Overhead guard height | 2150mm |
| Drive power | 6.3kw | |
| Load handing power | 7.5kw | |
| Power steering power | 0.85kw |
| Front | 960mm | |
| Rear | 980mm |
| Front | 7.00-12-12PR | |
| Rear | 18*7-8-14Pr |
| Rated Power | 48/630V/Ah | |
| Rated Capacity | 2500kg | |
| Service Weight | 4080kg | |
| Load center | 500mm | |
| Max.lifting height | 3000mm | |
| Fork free lift height | 110mm | |
| Max.lifting speed (loaded) | 280mm/s | |
| Tilt angle(fwd/bwd) | 6°/12° | |
| Transmissions type | Eletromtion | |
| Max.travel speed(l/ll) | 13km/h | |
| Max.gradeability(loaded) | 12% | |
| Turning radius | 1065mm | |
| Ground clearance | 120mm | |
| Fork size (lengthxwidthxthick) | 1070*120*40mm | |
| Wheel base | 1500mm | |
| Fork overhang | 471mm | |
| Min.right angle stacking aisle width | 3700mm | |
| Min.right angle aisle width | 2000mm | |
| Battery model-Voltage/Capacity | D630-48/630 | |
| Control | H2B |
Dimensions
electromotor
Track
Tyre
| Length | -L | |
| Width | -W | |
| Mast lowered height | -H1 | |
| Mast extended height | -H2 | |
| Overhead guard height | -H3 |
| Drive power | - | |
| Load handing power | - | |
| Power steering power | - |
| Front | - | |
| Rear | - |
| Front | - | |
| Rear | - |
| Rated Power | 48/630V/Ah | |
| Rated Capacity | 5512lb | |
| Service Weight | 8995lb | |
| Load center | - | |
| Max.lifting height | -H | |
| Fork free lift height | -Hs | |
| Max.lifting speed (loaded) | - | |
| Tilt angle(fwd/bwd) | - | |
| Transmissions type | - | |
| Max.travel speed(l/ll) | - | |
| Max.gradeability(loaded) | - | |
| Turning radius | -R | |
| Ground clearance | -H4 | |
| Fork size (lengthxwidthxthick) | -L2 | |
| Wheel base | -L1 | |
| Fork overhang | -L3 | |
| Min.right angle stacking aisle width | -L5 | |
| Min.right angle aisle width | -L4 | |
| Battery model-Voltage/Capacity | - | |
| Control | - |
