Specifications
nice looking , good quality, well reputation
Electrical Characteristics
Model |
AP-4-MG |
Optimum Operating Voltage (Vmp) |
18.00 V |
Optimum Operating Current (Imp) |
0.22A |
Open - Circuit Voltage (Voc) |
21.6 V |
Short - Circuit Current (Isc) |
0.23A |
Maximum Power at STC (Pmax) |
4 W |
Operating Module Temperature |
-40 °C to +85 °C |
Power Tolerance |
±3 % |
Mechanical Characteristics
Solar Cell |
Monocrystalline |
No. of Cells |
36 |
Dimensions |
245*205*18mm |
Weight |
0.68kgs |
Front Glass |
3.2 mm tempered glass |
Frame |
Anodized aluminium alloy |
Junction Box |
IP67 rated |
Output Cables |
TUV (2Pfg1169:2007), UL 4703, UL 44 |
|
Optional 4.0 mm2,symmetical lengths(-)1000mm and (+)1000mm |
B. 100% A grade solar cell with Positive tolerance power range.
C. High Conversion Efficiency , High transmission rate , low iron tempered Anti-reflecting/coating film 3.2mm glass
D. Anti-aging & high visosity EVA
E. high frame resistant & Double-sided fluorine TPT
F. Anodized aluminum alloy high thickness frame
G. 3 or 6 bypass diodes , 90mm 4m2 cable , MC4 connectors & waterproof junction box
H. Long life, Easy installation, high wind & hail impact resistance
I. Be resistant to atmospheric exposure & effects of delamination
Shenzhen Aten Photovoltaic Technology Co.,Ltd is a
young and rapidly growing company within solar panels , solar modules.
solar street lights ,solar rechargeable lights, inverters ………and integrate
development and manufacturing in house. We have complete and scientific
quality management systems, Our well-equipped facilities and excellent
quality control throughout all stages of production line to ensure that
eliminate quality concerns of our customers.
We are also in the position in according to customers’ demands
to make a design of solar system. As all customers trusted supplier
is what we pursuit all the time! Our hope is to secure the health of
our planet to future generation by transforming our infinite supply
of sunshine into a practical energy for humanity.
