factory direct high quality AC to DC slim switching power supply 15w 5v 3a LED driver, 12v slim power source switching
OEM welcome
Low price and high reliability
105Celsius degree output capacitor
Universal AC input
High efficiency and low operation temperature
Soft-start current can reduce the AC input impact effectively
With short-circuit and overload protection
Compact size,light weight
100% full-load burn-in test
Install with EMI filter,minimum wave
Model |
MD-15-3.3 |
MD-15-5 |
MD-15-12 |
MD-15-24 |
DC Output voltage |
3.3 V |
5 V |
12 V |
24 V |
Output voltage range(Note:2) |
±2% |
±1% |
±1% |
±1% |
Rated output current |
4A |
3 A |
1.3 A |
0.6 A |
Output current range |
0 ~ 4 A |
0 ~ 3 A |
0 ~ 1.3 A |
0 ~ 0.6 A |
Wave and noise(Note:3) |
75 mvp-p |
75 mvp-p |
50 mvp-p |
50 mvp-p |
Inlet stability(Note:4) |
±0.5% |
±1% |
±1% |
±1% |
Load stability(Note:5) |
±3% |
±0.5% |
±1% |
±0.3% |
DC output power |
9.9 W |
10 W |
12 W |
12 W |
Efficiency |
75% |
78% |
80% |
84% |
Adjustable range for DC voltage |
±10% |
±10% |
±10% |
±10% |
AC input voltage range |
85~264VAC 47~63Hz, 120~370VDC |
|||
Input current |
0.23A/230V |
|||
Power factor |
0.55-0.65 |
|||
AC Inrush current |
23A/230V |
|||
Leakage current |
<0.5mA/240VAC |
|||
Overload protection |
105%-150% Type: cut down output. Reset: auto recovery. |
|||
Temperature coefficient |
±0.03%/°C |
|||
Setup, rise, hold up time |
1s, 100ms, 50ms |
|||
Vibration |
10~500Hz, 2G 10min,/1 cycle. Period for 60min, Each axes |
|||
Withstand voltage |
I/P-O/P:1.5KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC |
|||
Isolation resistance |
I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC |
|||
Working temperature and humidity |
(-10 °C )~+60 °C, 10% - 95% RH |
|||
Store temperature and humidity |
(-20 °C )~+85 °C, 10% - 95% RH |
|||
Overall dimension |
78*48*21 mm |
|||
Weight |
0.1Kg |
|||
Safety standards |
GB4949, UL60950, EN60950 |
|||
EMC standards |
According to GB9254 EN55022 EN55024 A level design |
|||
|
Note: 1. The parameter under the testing condition: 230VAC input, rated load, 25°C70% RH. Temperature. 6. Each output can reach maximum current, but total load cannot exceed a maximum output power. | ||||
