1Ton 600KW fast coreless induction melting furnace
(KGPS600kw-0.8KHZ-1000kg)
1 Technical parameter:
Rated power: 600KW |
Rated capacity: 1000kg |
Rated input voltage: 380V |
Melting rate: about 1000kg/h |
Rated output voltage:1500V |
Power consumption: about600KW.H/T |
Rated input current:960A |
Cooling water consumption:18T/H |
Rated input frequency:50/60HZ |
Input water pressure:0.2Mpa |
Rated output frequency:0.8KHZ |
Recommend Transformer: 630KVA |
Weight:4500kg |
Volume:13CBM |
2 Equipment list
NO. |
Name |
Specification |
Qty |
1 |
Power control panel |
KGPS600-0.8 1300mm*900mm*1850mm |
1 set |
2 |
Compensation Capacitor cabinet |
1500mm*1500mm*700mm |
1 set |
3 |
induction furnace |
1400mm*1400mm*1400mm GW-1T |
2 sets |
4 |
Mechanical tilting control system |
Two speed reducer with two supporters
|
2 sets |
5 |
Water Cooling cables |
5m |
4 pcs |
6 |
Internal circulation cooling system |
Consist of pump and heat exchanger etc (this is for cooling power control panel) |
1 set |
7 |
Pouring control box |
200mm*300mm*400mm |
1 pcs |
8 |
Open cooling system |
Cooling tower with pumps |
1 set |
Our company
Yiphee Electric Crucible Furnace passed ISO international quality system certification and EU CE Certification,and induction melting furnace for iron have been sold to many contries,such as Europe, Belarus, Russia, Kosovo, Portugal, Africa, Libya, Zambia, Zimbabwe, South America, Ecuador, Peru, Brazil, North America, Asia, Hong Kong, Vietnam, Malaysia, Indonesia, Myanmar, Saudi Arabia, Lebanon, Bahrain, Tajikistan, Uzbekistan, North Korea, Poland, Iran,Colombia, Australia,Iran,etc.
Welcome to visit us!
