Log Trailer Crane ZM3004,3 TonTimber Trailer With Crane,Tractor Mounted Model((1 Ton,3 Ton,5 Ton,8 Ton,10ton,12 Ton) )

Log Trailer Crane ZM3004,3 TonTimber Trailer With Crane,Tractor Mounted Model((1 Ton,3 Ton,5 Ton,8 Ton,10ton,12 Ton) ) thumbnail-1
Log Trailer Crane ZM3004,3 TonTimber Trailer With Crane,Tractor Mounted Model((1 Ton,3 Ton,5 Ton,8 Ton,10ton,12 Ton) ) thumbnail-2
Log Trailer Crane ZM3004,3 TonTimber Trailer With Crane,Tractor Mounted Model((1 Ton,3 Ton,5 Ton,8 Ton,10ton,12 Ton) ) thumbnail-3
Log Trailer Crane ZM3004,3 TonTimber Trailer With Crane,Tractor Mounted Model((1 Ton,3 Ton,5 Ton,8 Ton,10ton,12 Ton) ) thumbnail-4
Log Trailer Crane ZM3004,3 TonTimber Trailer With Crane,Tractor Mounted Model((1 Ton,3 Ton,5 Ton,8 Ton,10ton,12 Ton) ) photo-1
Log Trailer Crane ZM3004,3 TonTimber Trailer With Crane,Tractor Mounted Model((1 Ton,3 Ton,5 Ton,8 Ton,10ton,12 Ton) ) photo-2
Log Trailer Crane ZM3004,3 TonTimber Trailer With Crane,Tractor Mounted Model((1 Ton,3 Ton,5 Ton,8 Ton,10ton,12 Ton) ) photo-3
Log Trailer Crane ZM3004,3 TonTimber Trailer With Crane,Tractor Mounted Model((1 Ton,3 Ton,5 Ton,8 Ton,10ton,12 Ton) ) photo-4
US$ 4980.00 - 4980.00 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, Log Trialer Crane
Use:
Log Ladinng
Contact Supplier Request Quote Chat Now
Shandong Sunco Agricultural Equipment Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Shanghai Tianjin Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Other, Log Trialer Crane
Use Log Ladinng
Power Type Diesel
Production Capacity 12 ton/ h
Place of Origin Shandong, China
Brand Name SAMTRA
Model Number ZM1002 to ZM12006
Dimension(L*W*H) 4348*1730*1258mm
Weight 1200kg
Certification CE Certificate
Warranty 12 Months
After-sales Service Provided Engineers available to service machinery overseas

 Log Trailer with Crane/ Timber Trailer with Grapple





Product Description



    ZM Series Log Loading Trailer for tractor is used in loading, unloading, transporting, stacking or unstacking

of wood, grass and reed, bamboo etc. Hydraulic transmission is used, featured with compact structure, flexibility, convenient operation, quick mounting and dismounting. It used hydraulic oil commonly with tractor. The hydraulic elements are highly standardized, convenient for operation and maintenance.





Application:



     ZM Series Log Loading Trailer for tractor is widely used in farm, grazing land, forestry work etc, mainly in

 loading, unloading,transporting, stacking or unstacking of wood, grass and reed, bamboo.



     ZM Series timber trailer with CE Certificate,and it can combined with different kinds tractors and ATV & UTV abroad, most our equipments be sold to Europe,Austalia,America and so on.





Model

ZM1002

ZM3004

ZM5004

ZM8006

ZM10006

ZM12006

Matching Power

10-25 hp

20-50 hp

30-60 hp

50-80 hp

70-100 hp

80 -140 hp

Machine Weight  (kg)

1010

1790

2040

2750

3000

3200

Trailer Section:

Trailer Model:

TR10

TR30

TR50

TR80

TR100

TR120

N/W of Trailer (kg)

420

690

940

1450

1700

1900

Rated Loading Capacity

1T

3T

5T

8T

10T

12T

Loading Area

0.85 m2

1 m2

1.6 m2

2.2 m2

2.5 m2

2.8 m2

Total Length of Trailer

3.6 m

5.1 m

5.1 m

5.9 m

6.3 m

6.3 m

Trailer Loading Length

2.0 m

3.1 m

3.1 m

3.8 m

4.3 m

4.3 m

Total Width of Trailer

1.4 m

1.6 m

1.8 m

2.2 m

2.3 m

2.5 m

Assistant Hydraulic Steering

No

Standard

Dia.of  Traction Hole

33 mm

38 mm

Tire Model

6.00 - 13

7.00 - 16

8.25 - 16

400/60-15.5

Crane Section:

Model

CR02

CR04

CR06

Weight of Crane (kg)

590

1100

1300

Max. Arm Reach

3.5 m

4.3 m

6 m

Lifting Capacity/Arm Reach (kg/m)



400/2,

300/3,

200/3.5

900/2,

760/3,

500/4,

450/4.3

990/2,

760/3,

500/4,

340/5,

240/6

Rotating Angle

370°

400°

400°

Grab Section:

Grab model

TG019

TG024

TG029

Weight of Grab(kg)

90

130

160

Max. Grab Opening Width(mm)

1140

1300

1430

Grabbing Dia. of Logs(mm)

80 - 420

70 - 485

75~530

Power  (option):

 PTO/ Gasoline Engine/ Diesel Engine









   Log Trailer Crane ZM3004,3 tonTimber Trailer with Crane,Tractor mounted model((1 ton,3 ton,5 ton,8 ton,10ton,12 ton) )Log Trailer Crane ZM3004,3 tonTimber Trailer with Crane,Tractor mounted model((1 ton,3 ton,5 ton,8 ton,10ton,12 ton) )Log Trailer Crane ZM3004,3 tonTimber Trailer with Crane,Tractor mounted model((1 ton,3 ton,5 ton,8 ton,10ton,12 ton) )



Log Trailer Crane ZM3004,3 tonTimber Trailer with Crane,Tractor mounted model((1 ton,3 ton,5 ton,8 ton,10ton,12 ton) )Log Trailer Crane ZM3004,3 tonTimber Trailer with Crane,Tractor mounted model((1 ton,3 ton,5 ton,8 ton,10ton,12 ton) )



Packaging & Shipping

 Log Trailer Crane ZM3004,3 tonTimber Trailer with Crane,Tractor mounted model((1 ton,3 ton,5 ton,8 ton,10ton,12 ton) )Log Trailer Crane ZM3004,3 tonTimber Trailer with Crane,Tractor mounted model((1 ton,3 ton,5 ton,8 ton,10ton,12 ton) )

Our Services



   We can provide  tractor  mounted backhoe ,front end loader,log trailer with crane have CE certifucate,we have professional engineers and production.

       We can provide you high quality products.

       Any Inquiry and visit is welcome



Company Information



  Our company is a comprehensive entity that inegrates sciencee ,indusry and trade together,mainly

engaged in scientific R&D,manufacture and technique service of modern agricultural equipment.



   We are the manufacturer of Agricultural Machinery from China. For example, Tractor Mounted Front Loader, Backhoe Excavator, Snow Sweeper, Snow Blades, Timber Trailer with Crane, Rotary Cultivator, Wood Chipper and Splitter etc. Moreover, we can manufacture parts for you and OEM Service is acceptable.

Log Trailer Crane ZM3004,3 tonTimber Trailer with Crane,Tractor mounted model((1 ton,3 ton,5 ton,8 ton,10ton,12 ton) )

FAQ



1.Production time :



     We arrange the production make-to-order,the production time is 25 days after we get the prepayment.



2.About the Certiifcate:



    Our ATV log loader has CE certificate.



3.About the Power :



   This ATV Log Loader,we can provide 6.5 hp diesel & Gasoline Engine.



4.Main Market:



   So far,we have exported the log loader for worldwide, America,Canada,France,Russia,Asia etc.
