Model JN-ID150C Industrial Oven for LED

Specifications

Industrial Dryer JN-ID150C

Product Description:
Industrial Dryer/Oven is suitable for drying variety of screen printing, pad printing, heat press and spraying thermosetting ink processing such as electric products, electrical engines, electric membrane film key press, silicon, window glass.

Overall body of the equipment uses the 1.5mm thickness steel plate, and interior door using 1.0 mm galvanized sheet. The surface is with high temperature varnish coated, and the appearance is novel. Microcomputer intellectualization control, the excess temperature warning, the overheated protection, the time establishment, controls the linearity to be good warm, after passing through dry especially, again by the base centrifugal fan inspiration, forms the reasonable air flue, can cause the hot air to transfer fully, the high temperature seal gate guaranteed that the internal temperature maximum limit achieves the uniform distribution to be consistent.

Features:
1. Box body structrue: Circular system, continuous operation in high temperature and composition of fans and a special air duct, the studio temperature uniformity.
2. Control systems: Smart temperature controller

Specification:
Inside size: 1200x900x1500mm
Temperature range: Normal~250oC
Voltage: AC 380V 50Hz
Power: 12KW
Constant temperature will be 5oC more or less
Temperature resolution: 1oC
Controller: The number obviously integrates controller
Heating system: Entire independent system, electric heating type heater
Fixed time scope: 1~999min
Safekeeping of security: The leakage, the short circuit, the excess imperature, the electrical machinery overheated, current protection.
