Specifications
1. Film output.2. Easy operation.
3. Max exports size: 310mm*Unlimited.
Laser film output machine JN-LF310W
| Models | JN-LF310W |
| Media Size | 12inch×Unlimited |
| Exposure Light | Semiconductor Laser |
| Resolution | 3000×3000dpi |
| Speed | 85mm/min |
| Repeatability | ± 0.01mm |
| Media Types | He-Ne Laser Film |
| Interface Type | USB2.0 |
| Process Mode | Use roll film in darkroom |
| Software | Rips4.0 |
| System Platform | PC Windows |
| Operation Environment | Temperature10-30°C, Humidity:20-80%. |
| Dimension | 660mm x 500mm x 550mm |
Descriptions:
This Series Laser Imagesetter is especially designed for direct pad printing & screen printing users. With RIP processing and multiple image setting choices inside, it can well meet users requirement of flexibility, safety, speed and low-cost.
This series adopt semiconductor lasers, which has a 100,000 hours long life. And with image control technology, even if being amplified a hundred times, it can still guarantee a clear and sharp spot edge.
Advantages:
1. Semiconductor luminescence lamp-house;
2. Flat operation mode;
3. Expert image controlling technology;
4. Film store box aggregated storing, measuring, cutting, feeding function installed;
5. RIP 3.0 sent with machine, used both PC AND MAC system;
6. Design for film ouput of pad printing & screen printing.
7. The roll film feeding , suitable for the negative of the output of any length and Positive Film.
