Stainless steel screen basket for pressure screen machine/ China screen machine for paper making
Working Principle
Pressure screen under the rotating function of drum sieve and rotating cylinder and centrifugation effect. The machine will separate the qualified pulp and non-qualified pulp.It consist of cylinder, cylinder cover, sieve drum, rotary cylinder,base and transmission parts, etc.
Slot screen for fine screen
Hole screen for coarse screen
Advantages of pressure screen
1. Many wing pieces, no winding, highly efficient rotary drum type rotor.
2. Pulp consistency can reach 2.5~4%, reduce water consumption and fiber loss of production process.
3. Heavy impurity discharge tube, ensure the security of the sieve drum operation.
4. Advanced structure, strong and durable, easy dismounting, low energy consumption, less wastage fiber.
5. Equipped with automatic oiling and mechanical seal water monitoring device, high degree of automation.
6. Compact structure, small power, high output.
7. 1 year warranty and best after-sale service
Customers
Technical parameter
Model NO. |
Screen Area (m2) |
Sieve hole size (mm) |
Seam Size (mm) |
Screen Hole (T/D) |
Screen Slot (T/D) |
Inlet pulp consistency (%) |
Motor Power (Kw) |
ZNS0.3 |
0.3 |
Φ1.6-Φ3.5 |
0.1-0.55 |
50-80 |
30-50 |
1-4 |
22-55 |
ZNS0.6 |
0.6 |
Φ1.6-Φ3.5 |
0.1-0.55 |
90-160 |
60-100 |
1-4 |
30-75 |
ZNS0.9 |
0.9 |
Φ1.6-Φ3.5 |
0.1-0.55 |
135-250 |
90-150 |
1-4 |
37-90 |
ZNS1.2 |
1.2 |
Φ1.6-Φ3.5 |
0.1-0.55 |
180-320 |
120-190 |
1-4 |
45-110 |
ZNS1.5 |
1.5 |
Φ1.6-Φ3.5 |
0.1-0.55 |
200-380 |
140-230 |
1-4 |
55-132 |
ZNS2 |
2 |
Φ1.6-Φ3.5 |
0.1-0.55 |
260-500 |
220-300 |
1-4 |
75-160 |
ZNS3 |
3 |
Φ1.6-Φ3.5 |
0.1-0.55 |
400-700 |
300-450 |
1-4 |
90-220 |
ZNS4 |
4 |
Φ1.6-Φ3.5 |
0.1-0.55 |
500-1000 |
350-730 |
1-4 |
132-280 |
Screen basket in pressure screen
Product Details
Delivery site
1.Pre-sales Service
- Offering comprehensive technical and business consultation services;
- Proposing the most suitable scheme and equipment for our clients;
- Designing and fabricating targeted products according to the special requirements of clients;
- Training periodically high qualified service technician.
2.After-sales Service
- Highly inspecting equipments in every working procedure, quality comes first;
- Fast & Safe Delivery;
- Assisting our clients for foundation construction of equipments;
- Dispatching engineers to install and debug equipments;
- Training the first-line operators on site;
- Regularly visit clients to solve production problems;
- Providing life-long maintenance service;
- Providing technical exchanging;
Zhengzhou Leizhan Technology Paper Machinery Co.,LTD is a professional manufacturer with more than 30 years manufacturing experience in making complete set of screening, impurity removal, pulping and refining equipment. Our company is located in Zhengzhou which is the hometown of machinery in Henan Province. We have more than 200 staffs including 50 engineering technicians which can be your best technical support. With high quality products and perfect pre-sale and after-sale service, we have won lots customers from all over the world.
Factory show
Workshop
Customers visit our factory
Exhibitions
Main products for paper pulp making
Paper making production lines we can provide
Waste paper pulp machine production line
Automatic corrugated box production line
Corrugated paper making production line
Fluting paper pulp making production line
Coated White Board Paper production line
Honeycomb Paper making production line
testliner paper making production line
Paper plate making production line
tissue paper making production line
toilet paper making machine line
kraft paper making machine line
boxboard paper machine line
Paper coating machine line
Napkin paper machine line
OCC line
Welcome to visit our factory. Any questions, contact us please!
