IEC60529 IPX3 and IPX4 Portable Water Spray Nozzle
US$ 750.00 - 750.00
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Chuangxin
Model Number:
CX-IPX4
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Portable Spectrometer With 10cm Integrating SphereUS$ 800 - 2,000MOQ: 1 Case -
Pocket Ir Radiometer Infrared IlluminanceUS$ 500 - 800MOQ: 1 Piece
-
UV Pocket Radiometer, Uv Radiometer,Digital Uv Radiometer,Dosimeter Radiometer Radiation MonitoringUS$ 500 - 1,000MOQ: 1 Set
-
Pocket UV Radiometer & Led Lighting Test Equipment Ir RadiometerUS$ 500 - 800MOQ: 1 Set
-
Led Tester Pocket UV Radiometer For Infrared IlluminanceUS$ 500 - 1,000MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
Chuangxin
Model Number
CX-IPX4
Power
Electronic
Usage
Other, Electric Safety Protection
IEC60529 IPX3/4 Water Spray Nozzle used for Waterproof Testing
IPX3-4 Spray Nozzle is a hand-held test device to verify protection against spraying and splashing water. The water pressure can be adjusted using the flow control knob on the device to give the required flow rate. The pressure can be seen on the gauge which is conveniently positioned by the nozzle. The spray pattern of the nozzle is made to the specifications of IEC 60529. A moveable shield can be put down over a portion of the nozzle for IPX3 or moved out of the spray pattern for IPX4.
Technical Parameters:
| Number of holes | Total 121 |
| Diameter of nozzle holes | 0.5mm |
| Material | Brass |
| Pressure gage range | 0 ~ 0.4Mpa |
| Pressure gage | 0 ~ 0.25Mpa |
| Water discharge | 10L/min, ±5%, can adjustment |
