Tungsten Alloy X-ray Gamma-ray γ-ray Collimator for Medical /Industrial inspection NDT/ Geologging Pipeline inspection
Geologging
Geologging is an exploration technique used mainly in the oil and gas industries. It is also known as wire line logging and borehole logging. A gamma ray source is lowered into a borehole and the radiation penetrates the rock strata. This data can then be analyzed to determine whether deposits of gas or oil are present. Tungsten alloy is used to shield the radioactive source and to act as a collimator for the gamma beam.
Pipe-line inspection Gamma
Radiation is used to inspect welds and to detect cracks in pipelines. A gamma source is mounted on a remote-controlled wheeled trolley (sometimes called a "pig") and travels inside the length of the pipe. A tungsten collimator is used to direct the radiation onto the target, whilst the radioactive source is housed inside tungsten shielding.
muti-Leave Collimators
MLC (Multi-leave collimators) primary role is to replace irregular handmade lead shield. Collimators (beam limiting devices) are used in linear accelerators used for radiotherapy treatments. They help to shape the beam of radiation emerging from the machine and can limit the maximum field size of a beam. The leaves of the collimators are made of tungsten alloy material which has much smaller damage than the lead material leaves. A collimators is composed of 120 tungsten alloy leaves.
Quick Response:feedback within 24hours
High quality:Well-trained workers and more than 10 years experience technical staff
Competitive price :Directly from factory to save your money.
Short lead time:sample 5-10days,large order about 20 days
Flexibility:order no matter how big or small all welcome
OEM & ODM both ok
We can offer various type with different functions for customers, not only manufacture according to the international standard, but also can design as per the requirements of customers.
Please choose freely from the wide range of already available Tungsten Alloy X-ray Gamma-ray Y ray Collimators/muti-Leave Collimators or contact us with your specifications.
Product display
Zhuzhou Newmetal Materials Co., Ltd is a refractory metal manufacturer specializing in the raw material and deep-processing product of tungsten, molybdenum, tantalum, niobium, rhenium and tungsten carbide.
• We have conquered the technological difficulties in welding between the tungsten carbide wear-resistant material and stainless steel-based and iron-based. The geometrical tolerance of weldment can be controlled in level A.
• Relying on powder metallurgy institute and engineering materials institute of Central South University, We have established a production-learning-research base to provide powerful technologic support for products R&D. And we have the whole production equipment from mixing to finish machining, including the world’s most advanced cold isostatic pressing machine which can manufacture the widest and longest plate.
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
