Home > Instruments & Meters > Test Instrument > Test Machine > CX-Z17 Laboratory Equipment Glow Wire Tester Flame Test Chamber
CX-Z17 Laboratory Equipment Glow Wire Tester Flame Test Chamber
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
CX
Model Number:
CX-Z17
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen Hongkong
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
UL94 Horizontal and Vertical Flammability TesterNegotiableMOQ: 1 Set -
CX-L19 IEC60112 Tracking Tester, Tracking Index ApparatusNegotiableMOQ: 1 Set
-
Hipot TesterNegotiableMOQ: 1 Piece
-
Factory 1000V Digital Insulation Resistance Tester/ Megger Insulation Resistance TesterNegotiableMOQ: 1 Piece
-
Programmable Hipot and Insulation TesterNegotiableMOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
CX
Model Number
CX-Z17
Power
Electronic
Usage
Other, Material Flammability Tester
CX-Z17 Glow Wire Tester Price
Product Description
Specification:
Glow Wire Test Instrument is according to IEC60695-2-1, IEC60695-2-13 (GB/T5169.10-2006~GB/T5169.13-2006), and UL746A, IEC829, DIN695, VDE0471, the glow wire Test Instrument CX-Z17 is suitable for resistance to abnormal heat and fire test on lighting lamps, electronic products and household appliances. Adopting high-temperature coating spraying on steel structure and imported instrument display, with easy operation, stable performance the equipment is applicable to flame resistance tests of all levels of QC departments and cooresponding enterprises.
Technology Parameters:
- Glow wire temperature: adjustable continuous within the range of 500~1000°c, the resolution of temperature is ±2°c
- Glowing time: 0.1~999.9s, ±0.1s ( time range is adjustable)
- Burning time: 0.1~999.9s, auto record and manual pause
- Flame chilling time: 0.1~999.9s, auto record and manual pause
- Glow wire pressure on test specimen: 1±0.2N. Limiting pressure depth is 7mm
- Glow wire: diameter is 4mm include nickel (80%) and chromium (20%) which made in specific dimensions
- Thermoelectric couple: φ0.5 armored nickel & chromium/ nidkel-chromium wire, K degree
- Auto break away: While reaching specified glowing time, test specimen will break away from glow wire automatically
- Working power supply: AC220V/50HZ and less than 500W
- Equipment dimension: W1100mm x D700mm x H1300mm
Company Introduction
Shenzhen Chuangxin Instruments Co., Ltd. are specialized in manufacturing special, custom built, test and measuring equipment for products testing as per international norms and offering calibration services and
related information. Our products and services are used by research & development establishments, test laboratories, defense establishments, government institutions &
manufacturing industries to fulfill the clients' requirements.
If you require equipment to test products such as home appliances, electrical accessories like switches, sockets, connectors, etc. industrial & road lighting luminaires,
automobile lighting systems or related categories, we can provide the solutions you need.
