Solar LED Reflective Traffic Sign,Solar LED Marker Light

Specifications

Solar LED Road Stud

FEATURES

1.  The road stud is produced by mould in one punch, no need to assemble, which greatly improve its load capability. Solar battery, electronic component and LED indicators are sealed in road stud with special technique, the road stud is strictly water proof, which can be used on ponding road for the long run.

2.   Upside of the road stud is designed with embossed parallel stiffeners which strengthen the stud and protect solar panel from being crushed by the wheels.

3.   Additional wear-resisting layer is increased on the upper surface, which prevents the surface from being wear away, and improve the efficiency of solar energy transfer.

4.   Intelligent control IC, imported precision potentiometer, heat-resistant high-volume rechargeable batteries are applied in the road stud, which ensure its service life and excellent performance.

5.   LED indicators are mounted in one side or double side according to customers’ requirement.

6.   The road stud is designed with handgrips and screw holes on both sides, which can be installed firmly on the road.

7.   Easy to install.

8.   The road stud is applicable to pavement, roadside edge, kerb stone, port and so on.

Model No.: BG-1205

Specifications

Power                       0.25W

Power Supply             solar cell (monocrystal silicon)

Battery                       600MA heat-resistant rechargeable battery

Material                      aluminum alloy shell and PC surface

Working Hours            continuously light 72 hours after exposed under strong sunlight for 8 hours.

Lighting Status            flash (2Hz±20%) or constant light

Light Color                  red, yellow, blue, white, green

Lighting Component    4 pcs φ5 high bright anti-fog LED on each side

Visible Rang               >800m

Life Span                    >3years

Working Temperature  -20°C~+70°C

Activate Condition       light intensity <500Lux

Size                           105*105*21mm

Package Size             48*40*35CM   100PCS/carton

Max Load Capacity     static pressure capability>12 tons

Weight

Net Weight               34kg/carton   0.31kg/pcs

Gross Weight            35kg/carton

Installation                  double fix the stud with adhesive and screw, make sure it will not loose under long term pressure.
