Signal 30 volt Miniature Power Relay Automatic Control ROHS 150mW coil power
Description:
Rohs and Reach Compliance
Miniature standard PCB layout
Small Size : 12.3 X 7.4 X 9.9 mm
High Sensitivity : 150mW coil power
Applications:
Remote Control
Communication Equipement
Modem Computer accessories
Sepecifications :
Signal Relay
PCB Power Relay
Lower Power Relay
Electromagnetic Relay
CHARACTERISTICS DATA
Insulation Resistance |
100MΩMin at 500VDC |
Dielectric Strength Between Open Contacts |
1000VAC(50/60Hz for one minute) |
Between Contacts and coil |
1500VAC(50/60Hz for one minute) |
Operate Time |
5 ms |
Release Time |
5 ms |
Temperature Range |
-30℃to+70℃ |
Shock Resistance |
Operating Extremes: 10G |
Damage Limits: 100G | |
Vibration Resistance |
10-55Hz, 1.5mm |
Weigh |
Approx 2.1 g |
Safety Standard |
Rosh and Reach Compliance |
Dongguan Yongneng Electronics is a medium-sized factory who specializes in RELAY field for 10
YEARS . We produce Signal Relay , PCB power relay and automotive relay and so on .
