Product Description
Spherical plain bearing
Features of spherical plain bearing
1. Material: the inner and outer rings are bearing steel(GCr15).
2. Heat Treatment: the inner and outer rings are quenched and phosphating.
3. Structure: There is no oil groove and oil hole in the inner and outer ring.The outer ring has an axial slot.
4. Sliding surface: coated with MoS2 powder lubricant.
5. Performance Characteristic: It has the advantages of abrasion resistance, corrosion resistance,and self aligning . It applies to the machine which requires heavy radial load and axial load in a small-range direction.
Catalog of GE ES / GE...ES 2RS/ GE...ES-2LS spherical plain bearing
Bore diameter: 15-240mm Outer diameter: 26-340mm ( suitable for both three types )
bearing with Suffix 2RS have a double lip seal on both sides of the bearing.
bearing with suffix -2LS have a sheet steel reinforced, triple-lip heavy-duty seal on both sides of the bearing.
Model |
Dimensions(mm) |
Weight(Kg) |
||
|
d |
D |
B |
|
GE15ES |
15 |
26 |
12 |
0.027 |
GE17ES |
17 |
30 |
14 |
0.041 |
GE20ES |
20 |
35 |
16 |
0.066 |
GE25ES |
25 |
42 |
20 |
0.119 |
GE30ES |
30 |
47 |
22 |
0.153 |
GE35ES |
35 |
55 |
25 |
0.233 |
GE40ES |
40 |
62 |
28 |
0.306 |
GE45ES |
45 |
68 |
32 |
0.427 |
GE50ES |
50 |
75 |
35 |
0.546 |
GE60ES |
60 |
90 |
44 |
1.04 |
GE70ES |
70 |
105 |
49 |
1.55 |
GE80ES |
80 |
120 |
55 |
2.31 |
GE90ES |
90 |
130 |
60 |
2.75 |
GE100ES |
100 |
150 |
70 |
4.45 |
GE110ES |
110 |
160 |
70 |
4.82 |
GE120ES |
120 |
180 |
85 |
8.05 |
GE140ES |
140 |
210 |
90 |
11.02 |
GE160ES |
160 |
230 |
105 |
14.01 |
GE180ES |
180 |
260 |
105 |
18.65 |
GE200ES |
200 |
290 |
130 |
28.03 |
GE220ES |
220 |
320 |
135 |
35.51 |
GE240ES |
240 |
340 |
140 |
39.91 |
Catalog of GEC spherical plain bearing
Inner Ring structure:
GEC and GECJ2 series are both bearing steel, throguh hardened and ground, sliding surface hard chromium plated.
Outer Ring strucutre:
GEC : Steel backsing with PTFE sintered bronze layor pressed around the inner ring, with a butt joint.
GECJ2: Steel backing with PTFE sintered bronze sleeve pressed around the inner ring without a butt joint.
Packaging & Shipping
Packaging:
Step 1: Plastic Bag + ODQ Single Color Box
Step 2: ODQ Standard Export Carton (Wooden Box FOR BIG ITEM )
Step 3: Standard Export Wooden Pallet with Plastic Film Against of Moisture.
Sample: Usually by EMS,DHL,UPS,TNT,FEDEX,Anyway as you like.
Bulk order : by air or sea
Product Category
1).Pillow block bearing:
INSERT BEARING: UC,UK,SER,SA,SB,CSA,CSB,HC,NA,UEL...
HOUSING: P,F,FS,FL,FC,T,PA,PH,HA,HB,PP...
2).Deep groove ball bearing:
6000,6200,6300,6900 series and Mini ball bearings (chrome steel,carbo steel,iron material)
3).Taper roller bearing:
Mm and inch size,single row,double row and four row
4).Spherical roller bearing:
22200 22300 23000 24000 series (steel cage CC,brass cage CA and MB)
5).Cylindrical roller bearing
NU,NJ,NUP,N,NF single row; NNU NN double row
6).Thrust ball bearing
Our Service
1.Our own brand or OEM service,any brand is available
2.Standard or Non standard item
3.Quick delivery & Cost saving
4.After sales service and technical assistance
5.Free sample is available
6.Before shipment,profucts will be strictly inspection on our factory QC process system
FAQ
Q:Are you a factory or trading company?
Guanxian YX Bearing CO.,LTD is specialized in manufacturing and exporting BEARINGS.
Q:Can I get some samples and do you offer the sample free?
A:Yes, sure, we are honored to offer you samples.If we have stock, we can send you free sample. And you just need to pay freight. If there have no stock, you need to pay sample fee and freight.
Q:Does the sample fee can be return back?
A: If you place an order, we can return part of sample fee even all of fee to you.It also depends on the Quantity of order and the type of sample.
Q:What is the MOQ for bearing?
A: Our MOQ is 1 PC
Company Information
Guanxian YX Bearing Co Ltd is a professional manufacturer and exporter of all types of pillow block bearings and taper roller bearings in chrome steel SAW 52100 as per international standard specification since 1986, which locates in Linqing Shandong China.
In the year 2012 we thought of incepting our own brand and then established it under the name TCT. After its marketing we received gradually the fruitful results and then we started increasing our product range on our customer demand. As a result of this today we are one of the renowned name among those companies who are selling over 1000 thousand different kinds of bearings.
Due to best quality standard, cleanlines, perfect packing and right time dellivery service, TCT bearings has been accepted in European, Middel East and African countries, exporting more than 80% of its production to more than 20 countries worldwide.
