YEMOO EVR20 Solenoid Valve High Quality NC Type Solenoid Valve for Sale

YEMOO EVR20 Solenoid Valve High Quality NC Type Solenoid Valve for Sale thumbnail-1
YEMOO EVR20 Solenoid Valve High Quality NC Type Solenoid Valve for Sale thumbnail-2
YEMOO EVR20 Solenoid Valve High Quality NC Type Solenoid Valve for Sale thumbnail-3
YEMOO EVR20 Solenoid Valve High Quality NC Type Solenoid Valve for Sale photo-1
YEMOO EVR20 Solenoid Valve High Quality NC Type Solenoid Valve for Sale photo-2
YEMOO EVR20 Solenoid Valve High Quality NC Type Solenoid Valve for Sale photo-3
US$ 50 - 200 MOQ: 2000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Beijing, China
Brand Name:
Danfoss
Model Number:
EVR20 solenoid valve
Contact Supplier Request Quote Chat Now
Hangzhou Yemoo Refrigeration Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Beijing, China
Brand Name Danfoss
Model Number EVR20 solenoid valve
Type Other, solenoid valve, EVR20 solenoid valve
Application Refrigeration Parts
Certification CE



 Can I help you ?

_______________________________________________

















Why choose it ?

___________________________________________



EVR is a direct or servo-type solenoid valve, using for fluid, suction and heat pipe with fluorinated refrigerants. EVR is available either as a single valve or the like separate components, i.e. valve body, coil and flanges (EVR 15) must be ordered separately.





Features:

1.     Can be used for various occasions like cold storage, freezing and air conditioning devices occasions.



2.     Provide normally closed style and normally open style.



3.     Wide selection of various AC or DC solenoid valve coil.



4.     Suitable for all fluorinated refrigerants.



5.     Design for medium temperature up to 105℃.



6.     MOPD of solenoid valve with 12W coil could be reached 25bar.



7.     Flare connection could be reached 5/8 inch.



8.     Soldering connection could be reached 2 1/8 inch.



9.     Extended nozzle for soldering connection

      ---let installation more convenient

      ---no need to dismounting valve body when soldering connection



10.  EVR also could provide flanges connection solenoid valve.







Technical data:



Refrigerant: CFC, HCFC, HFC

Medium temperature: 10W or 12W coil: -40~105℃

Defrosting period maximum temperature: 130℃







What you see is what you get ?



_______________________________________________

YEMOO EVR20 solenoid valve high quality NC type solenoid valve for sale

YEMOO EVR20 solenoid valve high quality NC type solenoid valve for sale

 YEMOO EVR20 solenoid valve high quality NC type solenoid valve for sale









 How about it ?



_______________________________________________



Type                  Standard coil solenoid
         valve open pressure differential
                               bar		    Medium temperature    Max.      working  pressure Kv value 1)
           Liquid Max.=MOPD 2)
     Min. 10W a.c. 12W a.c. 20W d.c.
EVR2 0 25 18 -40~105 45.2 0.16
EVR3 0 21 25 18 -40~105 45.2 0.27
EVR6 0.05 21 25 18 -40~105 45.2 0.8
EVR6 NO 0.05 21 21 21 -40~105 45.2 0.8
EVR10 0.05 21 25 18 -40~105 35 1.9
EVR10 NO 0.05 21 21 21 -40~105 35 1.9
EVR15 0.05 21 25 18 -40~105 32 2.6
EVR15 NO 0.05 21 21 21 -40~105 32 2.6
EVR20(a.c.) 0.05 21 25 13 -40~105 32 5
EVR20(d.c.) 0.05 16 -40~105 32 5
EVR20 NO 0.05 19 19 19 -40~105 32 5
EVR22 0.05 21 25 13 -40~105 32 6
EVR22 NO 0.05 19 19 19 -40~105 32 6
EVR25 0.2 21 25 18 -40~105 32 10
EVR32 0.2 21 25 18 -40~105 32 16
EVR40 0.2 21 25 18 -40~105 32 25
1)Kv value is water flow equal to 1 bar pressure differential when through solenoid valve, unit is m³/h, densityρ=1000kg/ m³
2)The MOPD of medium in gas form is about 1 bar





Type                                         Titular refrigeration capacity(KW)
                    Liquid                    Suction                     Hot gas
R22/R407C R134a R404A/  R507 R22/R407C R134a R404A/  R507 R22/R407C R134a R404A/  R507
EVR2 3.2 2.9 2.2 - - - 1.5 1.2 1.2
EVR3 5.4 5 3.8 - - - 2.5 2 2
EVR6 16.1 14.8 11.2 1.8 1.3 1.6 7.4 5.9 6
EVR10 38.2 35.3 26.7 4.3 3.1 3.9 17.5 13.9 14.3
EVR15 52.3 48.3 36.5 5.9 4.2 5.3 24 19 19.6
EVR20 101 92.8 70.3 11.4 8.1 10.2 46.2 36.6 37.7
EVR22 121 111 84.3 13.7 9.7 12.2 55.4 43.9 45.2
EVR25 201 186 141 22.8 16.3 20.4 92.3 73.2 75.3
EVR32 322 297 225 36.5 26.1 32.6 148 117 120
EVR40 503 464 351 57 40.8 51 231 183 188
Liquid and suction titular refrigeration capacity condition:
evaporating temp: -10℃
Before valve liquid temp: 25℃
Through solenoid valve pressure drop: p=0.15bar
Hot gas titular refrigeration capacity condition:
Condensing temp: 40℃
Through solenoid valve pressure drop: p=0.8bar
Hot gas temp: 65℃
Liquid refrigerant supercooling degree: t=4K







Valve body, normally closed type

Type Coil No. Connection size Code No.(valve body without coil)
Flare1)     ODF soldering
inch mm Inch/mm inch mm   With manual operation Without manual operation
EVR2 a.c. 1/4 6 032F8056 032F1201 032F1202
EVR3 a.c./d.c. 1/4 6 032F8107 032F1206 032F1207
 3/8 10 032F8116 032F1204 032F1208
EVR6  3/8 10 032F8072 032F1212 032F1213
1/2 12 032F8079 032F1209 032F1236
EVR10 1/2 12 032F8095 032F1217 032F1218
5/8 16 032F8098 032F1214 032F1214
EVR15 5/8 16 032F8101 032F1228 032F1228
5/8 16 032F81002) 032F1227
7/8 22 032F1225 032F1225
EVR20 a.c. 7/8 22 032F1240 032F1240
7/8 22 032F1254
9/8 28 032F1244 032F1245
d.c. 7/8 22 032F1264 032F1264
7/8 22 032F1274
EVR22 a.c. 11/8 35 032F3267 032F3267
EVR25 a.c./d.c. 9/8 032F2200 032F2201
28 032F2205 032F2206
11/8 35 032F2207 032F2208
EVR32 11/8 35 042H1105 042H1106
13/8 042H1103 042H1104
42 042H1107 042H1108
EVR40 13/8 042H1109 042H1110
42 042H1113 042H1114
17/8 54 042H1111 042H1112
1) Valve body supply is not including flare nut
2) With manual operation







Valve body, normally open type3)

Type Coil No. Connection size Code No.(valve body without coil)3)
Flare1) ODF soldering
inch mm inch mm inch mm
EVR6 a.c./d.c. 3/8 10 O32F8085 032F8085 032F1290 032F1295
EVR10 1/2 12 032F8090 032F8090 032F1291 032F1296
EVR15 5/8 16 032F8099 032F8099 032F1299 032F1299
7/8 22 032F3270 032F3270
EVR20 7/8 22 032F1260 032F1260
9/8 28 032F1269 032F1279
EVR22 a.c. 11/8 35 032F3268 032F3268
1) Valve body supply is not including flare nut
2) With manual operation
3) Coil in normal range could be used for various normally open type solenoid valve except 110V, 50/60Hz and 220V, 50/60Hz double frequency.











What can I get guarantee ?

_______________________________________________



1.We are Professional factory to make semi-hermetic compressor and condensing unit more than 10 years.

2.We insist on innovation,purchasing the international quality materials,strong  technique  support,strictly control the production.

3.We firmly believe quality first,perfect production responsibility system.

4.We promise all Yemoo brand products,we supply 3 months new products guarantee replacement,12 months quality guarantee service.



So,what Yemoo can support you ? It's best price ratio products,perfect after-sales service guarantee.

Yemoo's value is what we supply you is not only products,but also creating you most value.
