10hp YEMOO Semi-hermetic Piston Bitzer Open Type Compressor With Manual

10hp YEMOO Semi-hermetic Piston Bitzer Open Type Compressor With Manual thumbnail-1
10hp YEMOO Semi-hermetic Piston Bitzer Open Type Compressor With Manual thumbnail-2
10hp YEMOO Semi-hermetic Piston Bitzer Open Type Compressor With Manual thumbnail-3
10hp YEMOO Semi-hermetic Piston Bitzer Open Type Compressor With Manual thumbnail-4
10hp YEMOO Semi-hermetic Piston Bitzer Open Type Compressor With Manual photo-1
10hp YEMOO Semi-hermetic Piston Bitzer Open Type Compressor With Manual photo-2
10hp YEMOO Semi-hermetic Piston Bitzer Open Type Compressor With Manual photo-3
10hp YEMOO Semi-hermetic Piston Bitzer Open Type Compressor With Manual photo-4
US$ 400 - 3,000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
YEMOO(bitzer open type compressor)
Model Number:
YMB4-100
Contact Supplier Request Quote Chat Now
Hangzhou Yemoo Refrigeration Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shangai / Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name YEMOO(bitzer open type compressor)
Model Number YMB4-100
Type Other, Refrigeration Compressor, bitzer open type compressor
Application Refrigeration Parts
Certification CE



Product Description



1. Features:



1) Introdution

Developed technology, compact dimensions

Small volume and space

High precision machining to ensure the bitzer open type compressor confirm with the standard

CNC processing center

Concentricity due to specific processing technology

Minimal dead space

Steady operation, small vibration and low noise

Excellent stability

Refrigerant like R22 and R404 are adopted to protect the environment

For mid&low temperature application

Electrical motor protect device

PTC sensor

Wear resistant driver gear

Chrome plated piston rings and aluminum pistons

Hardened crank-shaft

Low friction bearing set

Efficient valve plate design, high refrigerating capacity and low energy consumption

Efficient compression rate

Valve reed made of imported impact resistant spring steel

General spare parts, convenient for maintenance



2)Wide range of application

   The bitzer open type compressor uses R22 as refrigerant. R134a, R404a, R407b and R407c are also approved. R12 and R502 are not suggested due to the international environment protection requirement. The machine can be used at a low or high condensing temperature.



3)Excellent performance

   The bitzer open type compressor has a scientific structure design, strictly chosen material and precise procession and it is strictly inspected. The factory has obtained the National Compulsory Products CCC Certification, the National Industrial Products Manufacture License, and the ISO9001:2008 International Quality Supervision System Certification.



4)Reliable safety device

  The bitzer open type compressor is equipped with motor protector and discharge temperature monitor to prevent the overheat of the motor and the bitzer open type compressor and the operation beyond approved application pressure.



2.Accessories of YEMOO Condensing unit:



Note: Our connecting welding rod is using Harris imported from USA. Other spare parts can based on the customer's requests.







Technical Data



Refrigerant Gas   R22 Refrigerating Capacity Q0 (W)
Model Condensing Temperature oC Evaporating Temperature oC
12.5 10 7.5 5 0 -5 -10 -15 -20 -25 -30 -35 -40
YMB4-100 30           35650 29250 23700 18940 14860 11330 7320 5220
40           31450 25700 20700 16390 12710 9500 5920 4010
50           27300 22150 17700 13800 10510 7700 4610 2910



Refrigerant Gas R404A/R507A Refrigerating Capacity Q0 (W)
Model Condensing Temperature oC Evaporating Temperature oC
7.5 5 0 -5 -10 -15 -20 -25 -30 -35 -40 -45
YMB4-100 30       38300 31600 25750 20700 16390 12690 9550 6910 4690
40       32300 26500 21500 17130 13400 10220 7520 5240 3350
50       21500 17290 13660 10550 7890 5640 3760

  10hp YEMOO semi-hermetic piston bitzer open type compressor with manual



Model Motor Power HP/KW Displa-cement (50/60Hz)     M³/h quantity of cylinder x Diameter x Stoke (mm) Suction,Discharge valve take-over  Oil Injection Volume (L) Power supply    V/Ø/Hz Electrical Parameter Cran-kcase heater (220V)W Oil supply method Weight (Including freezing oil) kg
DL SL (A) Max operating current  (A) Stating current/ rotor locked current
YMB2-020 2/1.5 13.4 2×Φ50×39.3 φ16(5/8") φ22 (7/8") 1.5 220-240 /380-420Y/3/5        •            265-290 /440-480Y/3/60       11.9/6.9 53.7/30.7 120 Centrifugal lubrication 67.5
YMB2-031 3/2.2 13.4 2×Φ50×39.3 φ16(5/8") φ22 (7/8") 1.5 13.5/7.8 64/37 120 70.5
YMB2-030 3/2.2 16.2 2×Φ55×39.3 φ16(5/8") φ22 (7/8") 1.5 14.8/8.5 64/37 120 70
YMB2-041 4/3 16.2 2×Φ55×39.3 φ16(5/8") φ22 (7/8") 1.5 16.4/9.4 76.6/44.2 120 70
YMB4-030 3/2.2 18.1 4×φ41×39.3 φ16(5/8") φ22 (7/8") 2 15.9/9.2 76.6/44.2 120 82
YMB4-051 5/3.7 18.1 4×φ41×39.3 φ16(5/8") φ22 (7/8") 2 18.7/10.8 107.7/62.2 120 86
YMB4-040 4/3 22.7 4×φ46×39.3 φ16(5/8") Φ28 (1+1/8") 2 18.5/10.7 92.7/53.2 120 84
YMB4-061 5/3.7 22.7 4×φ46×39.3 φ16(5/8") Φ28 (1+1/8") 2 22.9/13.2 107.7/62.2 120 86
YMB4-050 5/3.7 26.8 4×φ50×39.3 Φ22 (7/8") Φ28 (1+1/8") 2 23.4/13.5 107.7/62.2 120 85.5
YMB4-071 7/5.1 26.8 4×φ50×39.3 Φ22 (7/8") Φ28 (1+1/8") 2 27.5/15.9 142.8/82.4 120 88.5
YMB4-060 6/4.4 32.5 4×φ55×39.3 Φ22(7/8") Φ28 (1+1/8") 2 27.5/15.9 142.8/82.4 120 90.5
YMB4-091 9/6.6 32.5 4×φ55×39.3 Φ22 (7/8") Φ28 (1+1/8") 2 34.5/20 142.8/82.4 120 90.5
YMB4-080 8/5.5 41.3 4×φ60×42 Φ28 (1+1/8") Φ35 (1+3/8") 2.6 380-420YY/3/50  •             440-480YY/3/60 17 49/81 120 134
YMB4-121 12/8.8 41.3 4×φ60×42 Φ28 (1+1/8") Φ35 (1+3/8") 2.6 24 69/113 140 141
YMB4-100 10/7.5 48.5 4×φ65×42 Φ28 (1+1/8") Φ35 (1+3/8") 2.6 21 59/99 140 139
YMB4-151 15/10.5 48.5 4×φ65×42 Φ28 (1+1/8") Φ42 (1+5/8") 2.6 31 81/132 140 147
YMB4-120 12/8.8 56.2 4×φ70×42 Φ28 (1+1/8") Φ35 (1+3/8") 2.6 24 69/113 140 141
YMB4-201 20/15 56.2 4×φ70×42 Φ28 (1+1/8") Φ42 (1+5/8") 2.6 37 97/158 140 150





Detailed Images

  10hp YEMOO semi-hermetic piston bitzer open type compressor with manual10hp YEMOO semi-hermetic piston bitzer open type compressor with manual10hp YEMOO semi-hermetic piston bitzer open type compressor with manual













Packaging & Shipping













Our Services



1.We are Professional factory to make semi-hermetic compressor and condensing unit more than 10 years.

2.We insist on innovation,purchasing the international quality materials,strong  technique  support,strictly control the production.

3.We firmly believe quality first,perfect production responsibility system.

4.We promise all Yemoo brand products,we supply 3 months new products guarantee replacement,12 months quality guarantee service.



So,what Yemoo can support you ? It's best price ratio products,perfect after-sales service guarantee.

Yemoo's value is what we supply you is not only products,but also creating you most value.







Certifications











Our workflow



10hp YEMOO semi-hermetic piston bitzer open type compressor with manual10hp YEMOO semi-hermetic piston bitzer open type compressor with manual
