Type Compressor
Place of Origin Zhejiang, China
Brand Name YEMOO
Model Number YMB4-061
Certification CE, ROHS
After-sales Service Provided Overseas third-party support available



Product Description



1. Features:



1) Introdution

Developed technology, compact dimensions

Small volume and space

High precision machining to ensure the compressor confirm with the standard

CNC processing center

Concentricity due to specific processing technology

Minimal dead space

Steady operation, small vibration and low noise

Excellent stability

Refrigerant like R22 and R404 are adopted to protect the environment

For mid&low temperature application

Electrical motor protect device

PTC sensor

Wear resistant driver gear

Chrome plated piston rings and aluminum pistons

Hardened crank-shaft

Low friction bearing set

Efficient valve plate design, high refrigerating capacity and low energy consumption

Efficient compression rate

Valve reed made of imported impact resistant spring steel

General spare parts, convenient for maintenance



2)Wide range of application

   The Compressor uses R22 as refrigerant. R134a, R404a, R407b and R407c are also approved. R12 and R502 are not suggested due to the international environment protection requirement. The machine can be used at a low or high condensing temperature.



3)Excellent performance

   The compressor has a scientific structure design, strictly chosen material and precise procession and it is strictly inspected. The factory has obtained the National Compulsory Products CCC Certification, the National Industrial Products Manufacture License, and the ISO9001:2008 International Quality Supervision System Certification.



4)Reliable safety device

  The compressor is equipped with motor protector and discharge temperature monitor to prevent the overheat of the motor and the compressor and the operation beyond approved application pressure.



2.Accessories of YEMOO Condensing unit:



Note: Our connecting welding rod is using Harris imported from USA. Other spare parts can based on the customer's requests.







Technical Data



Refrigerant Gas   R22 Refrigerating Capacity Q0 (W)
Model Condensing Temperature oC Evaporating Temperature oC
12.5 10 7.5 5 0 -5 -10 -15 -20 -25 -30 -35 -40
YMB4-051 30 24400 22350 20500 18720 15540 12780 10390 8320 6550 5030 3740
40 21800 19960 18250 16650 13750 11230 9040 7150 5530 4130 2950
50 19180 17530 15980 14530 11920 9640 7660 5950 4480 3220
YMB4-040 30           15780 12860 10350 8820 6930 5340 4010 2910
40           13840 11180 8880 7550 5860 4440 3270 2300
50           11860 9450 7360 6160 4690 3450 2420
YMB4-061 30 29950 27500 25200 23050 19160 15800 12880 10360 8200 6350 4780
40 26750 24500 22400 20450 16930 13860 11190 8890 6910 5210 3770
50 23450 21450 19570 17810 14630 11850 9440 7350 5560 4020



Refrigerant Gas R404A/R507A Refrigerating Capacity Q0 (W)
Model Condensing Temperature oC Evaporating Temperature oC
7.5 5 0 -5 -10 -15 -20 -25 -30 -35 -40 -45
YMB4-051 30 21550 19790 16590 13810 11400 9320 7500 5970 4650 3530 2580
40 18240 16740 14020 11650 9580 7790 6240 4900 3760 2790 1970
50 14970 13730 11470 9500 7780 6280 4980 3860 2900 2090 1410
YMB4-040 30       17330 14290 11660 9400 7450 5800 4390 3210 2220
40       14440 11870 9650 7720 6070 4650 3450 2440 1590
50       11650 9550 7720 6130 4760 3590 2590 1750
YMB4-061 30 27500 25200 21100 17580 14500 11830 9530 7550 5860 4420 3210
40 23150 21250 17780 14750 12120 9840 7860 6160 4700 3470 2420
50 18930 17360 14490 11980 9790 7890 6240 4820 3600 2570 1710



Yemoo 6HP Semi-hermetic piston refrigeration Bitzer chiller compressor brands for cold room





 Yemoo 6HP Semi-hermetic piston refrigeration Bitzer chiller compressor brands for cold room

Detailed Images

Yemoo 6HP Semi-hermetic piston refrigeration Bitzer chiller compressor brands for cold roomYemoo 6HP Semi-hermetic piston refrigeration Bitzer chiller compressor brands for cold roomYemoo 6HP Semi-hermetic piston refrigeration Bitzer chiller compressor brands for cold room













Packaging & Shipping













Our Services



1.We are Professional factory to make semi-hermetic compressor and condensing unit more than 10 years.

2.We insist on innovation,purchasing the international quality materials,strong  technique  support,strictly control the production.

3.We firmly believe quality first,perfect production responsibility system.

4.We promise all Yemoo brand products,we supply 3 months new products guarantee replacement,12 months quality guarantee service.



So,what Yemoo can support you ? It's best price ratio products,perfect after-sales service guarantee.

Yemoo's value is what we supply you is not only products,but also creating you most value.
