| max power | 100W |
| operating temperature | -40to+85°c |
| maximum system voltage | 1000V DC |
| NOCT | 48°c±2°c |
| current temperature coefficient(%/k) | 0.06±0.01 |
| voltage temperature coefficient(mv/k) | -(155±10) |
| power temperature coefficient(%/k) | -(0.5±0.05) |
| type of output terminal | junction box |
| cable | 900mm,LAPP(4.0mm²) |
| connection | standard plug and socket |
| solar cell | poly-crystalline silicon solar cell 156mm*156mm |
| type of solar cell | type p |
| No.of cells and connections | 36(4*9) |
| weight | 12.5kg |
| applications | solar lights,household solar power systems,etc |
High efficiency solar cells ensure high performance of solar module and create maximum power output.
We have many kinds of solar panels,5W-300W.
Solar Cell:High efficiency solar cells ensure high performance of solar module and create maximum power output.
Low lron Tempered Glass:Anti-reflecting coating and high transmission rate glass increase the power output and
mechanical strength of solar module.
Aluminum Frame:Without screw,corner connection.10holes on the frame can be installed easily.
Supperor Junction Box: Multi function junction box with water proof capabilities.
Long Lifespan:>=25 years.
Tolerance:+/-3%.
Good performance of preventing from atrocious weather such as wind and hails.Resisting moisture and etching
effectively,not effect by
The certificate issued by international authority:CE,TUV,IEC.
