Cheap and high quality edge banding machine
1) Possess of functions such as automatic bending ,lipping Notching ,cutting !
2) Imported steel for bending mould which is tough, high strength, durable.
3) Unique rotary cutting mode and rotary lipping mode.
4) Through the gear ball screw rail transmission, high precision and stable
5) Self-developed updated automatic bending control system with powerful function
6) Complete English interface ,easy to learn and use!
Applicable materials:
Specially for Cutting plywood die board, also cut MDF, Acrylic !
Applicable industry:
Packing industry, Printing Industry, Box dies, Sticker dies, Toys dies, Electronic parts dies etc.
Technical Parameters
| Rule (thickness) | 2pt 0.71mm | 3pt 1.07mm | |||||
| Rule (height) | 23.8mm | 23.8mm | |||||
| Max Bending R | 100° | 90° | |||||
| Min R in 90° | 0.5 | 0.8 | |||||
| Minimum bending size on front | 1.8 | 2.5 | |||||
| The back of the Minimum bending size | 0.5 | 0.5 | |||||
| Function | bending | Notching | Cutting | lipping | |||
| Feeding Accuracy | ±0.03mm | ||||||
| Bending Flatness | 0.2/100mm | ||||||
| The way of cut | up down cut | ||||||
| The best graphics formats | dxf format | ||||||
| Air pressure | 0.8mpa | ||||||
| Voltage and Frequency | 220V 50/60Hz (standard) | ||||||
| Gross Power | 2000W | ||||||
| Machine Size and Weight | 2700x1050x1350 480kgs | ||||||
| Rule Height | 8mm-25mm | ||||||
a. Machine Standard production One Year Warranty
b. Advanced Team 7*12hrs online service(E-mail, Skype WeChat, Whatsapp,Teamviewer)
c. Manual, Software, Video, CD
d. Free training in factory
e. Technician local service available
1)Can I use this Machine for 2pt and 3pt rule bending?
Yes, Machine along with two bending heads, one for 2pt blades bending, another headsfor 3pt blades bending, you just need to exchange the head will be ok, and it is easy, just release and tighten 4 screws. .
2) If I want to use this machine to bend 4pt blades, is it possible ?
The answer is yes, but you have to talk with us before you order, we need to customized the machine for you.
3)Can I use this machine for Rotary dies making ?
This machine is design for Flat dies, for rotary dies please write to us for another machine.
4)how much total power of the whole machine ?
It will be around 2KW.
5)How much air pressure for the Machine ?
0.8MPA will be ok, we use Motor to press the mould for cutting, lipping and Notching, More powerful!
6) What will be the consumable parts of this machine ?
A.Bending Heads.
B.Lipping, Notching, Cutting Mould
7) Do you have engineer for local installation in my factory ?
Yes, we will send engineer to your for installation and training if you carrie round trip air tickets and accommodation fee, free training in our factory.
8) Can I come to you for Die manual accessories and materials?
YES, we have full solutions of the laser die cutting, both the flat dies and rotary dies, it is our pleasure to help you.
if more questions, please feel free to contact with us.
Looking for agents all over the world! Any questions, welcome to contact us! click here
