Product Description

8x RF Tuners FTA to IP Gateway and Multiplexed

IRD1218 Professional 8-channel RF to IP Gateway that Integrates Professional DVB-S2,Cable(DVB-C), ISDB-T,ATSC RF Receivers and De-encapsulates and Routes Any or All Selected Transport Streams via IP Output Port by SPTS/MPTS channels, with re-multiplexing and scrambling of multiple transport streams.

The IRD1218 enables an all-IP headend architecture,resulting in a more scalable and lower-cost transition to IP-based services.

It will be a ideal equipment for the IPTV network head and deliver the SPTS channels to next equipment which the transcoder and IPTV server,can much save the cost in your investment.


IRD1218 Rear panel


Feature

1.Up to 8 channels FTA Tuners per chassis

2.Professional DVB-S2,ISDB-T,ATSC DVB-C RF inputs option

3.Up to 244 streams-over-IP in SPTS/MPTS mode

4.Up to 2 separate ASI out after multiplexed

5.Support processing for multiplexing,scrambling,

6.PSI/SI Table in Mpts mode

7.Support BISS function（Extra charge）

8.De-encapsulates and Routes Any or All Selected Transport Streams outputs

9.Data stream Protocol of UDP, RTP

10.PID filtering, mapping and pass through

11.Easy-to-Use System Management

12.Output data rate range: GbE IP:1 ~ 800Mbps

ASI: 1-100Mbps

13.Management via WEB and local front panel

14.Integrated, compact 1-RU platform saves rack space and reduces operating costs

Tuner input
DVB-S/S2 RF In
Comply to DVB-S/S2, DVB / DSS standard
Input frequency range: 950～2150MHz
Input level: -25～-65dBm
Connector: F-female type, 75ohm
Symbol rate: 2～45Msps for QPSK;2～45Msps for 8PSK
Rolling off factory:0.35 for QPSK;0.35,0.25,0.2for 8psk
Convolution encoding Rates:
DVB-S QPSK: 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 8/10 ;
DVB-S2 8PSK: 3/5, 2/3, 3/4, 5/6, 8/9, 9/10
8 channels RF inputs and loop out
DVB-C RF
Demodulation : 16/32/64/128/256 QAM
Bandwidth : 6MHz、7MHz、 8MHz
Input Frequency : 30～860MHz
Input level: -20～20dBmV
Connector: F-female,75 ohm
8 channels RF inputs and loop out
ISDB-T RF In
Compliant with ARIB STD-B31 standard
Input frequency range: 30～900MHz
Bandwidth 6MHz
Constellation DQPSK,QPSK, 16QAM, 64QAM
Interleave 0, 4, 8, 16
Guard Interval 1/32, 1/16, 1/8, 1/4
Transmission Mode 2K, 4K, 8K (FFT)
FEC (Code Rate) 1/2, 2/3, 3/4, 5/6, 7/8
ATSC RF In
Compliant with ATSC A/53 standard
Input frequency range: 30～900MHz
Demodulation: 8VSB
ASI output
2x independent ASI output, BNC, impedance: 75Ω
188 bytes per packet
Bitrate: ≤100mbps
comply to EN50083-9, ASI standard
MPEG-TS OVER IP Output
1000M base-T,Full Duplex
Bit rate: ≤800Mbps
Data Protocol: UDP/RTP, Multicast/Unicast
Both MPTS/SPTS Mode
Stream number: 1~244（MPTS mode）
7x188 bytes per udp packet
Multiplexing
PSI/SI table(PAT,PMT,NIT,TOT,TDT,BAT) automatic or manual generate
Up to 512 programs to multiplex,and 64 service id per one MPTS out
PID Filter capabilities
Scrambling (option)
Up to 512 programs to scrambling
CAS simul- encryption:0-4
EMM of bandwidth:1-3Mbps
The scrambling function and configures the numbers of output modulation channel through software authorization
System function
100M Base-T Ethernet, RJ45,WEB((IE 8.0 or above)
6 keys: UP, DOWN, LEFT, RIGHT, ENTER,ESC
Front-Panel LCD configuration, LED indicate light
Environment
Power Supply:AC 90-260V  50/60Hz
Power consumption: 50W
temperature:0~45℃(Operation), -20~80℃(Storage)
Dimensions:L: 460mm, W: 483mm, H: 44mm(1RU)
Weight: 6Kg
