2015 Newest C-DOCSIS/DOCSIS 3.0 Cable Modem Terminal System

Name: 2015 Newest C-DOCSIS/DOCSIS 3.0 Cable Modem Terminal System
Brand: DIBSYS
SKU: 110656209
Availability: InStock

2015 Newest C-DOCSIS/DOCSIS 3.0 Cable Modem Terminal System thumbnail-1

2015 Newest C-DOCSIS/DOCSIS 3.0 Cable Modem Terminal System photo-1

US$ 1 - 5,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

DIBSYS

Model Number:

DB-CM301

Contact Supplier Request Quote Chat Now

Hangzhou DIBSYS Technologies Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name DIBSYS

Model Number DB-CM301

Dibsys Cable Moderm

Overview

DOCSIS system include CMTS(Headend cable network ) and CM(user end).The main function of DOCSIS Cable Modem system is transparently transmitting IP packets between the front end and

the user end.

Technical principle
After the Modem Cable power, the downlink frequency of the front end is automatically searched,

and the downstream frequency is found, the uplink channel is determined from the downlink data.CMTS is connected with the front-end device, and exchange information, including the upstream level, the Dynamic Host Configuration Protocol (DHCP) and the IP address of the small file transfer protocol (TFTP) server, etc.Modem Cable has online features, even if the user does not use, as long as the power is not cut off, and the front end always to maintain the exchange of information, the user can always on-line.
Cable moderm has memory function, when the power is powered up, the data before the power storage are exchanged with the front data , and can quickly complete the search process.

CM online process

Key Features

l The definition is according to C-DOCSIS standard, meet europe DOCSIS 3.0/DOCSIS 3.0

l 10/100/1000RJ45 ethernet adaptive port, advanced firewall and 802.11n wireless access

l Downstream is 8 frequency points, upstream is 4 frequency points

l Downstream frequency is 108MHz to 1000MHz,64QAM,256QAM and 1024QAM

l Upstream frequency is 5 to 65MHz, QPSK,8/16/32/64/128/256QAM

Technical specifications

Model	DB-CM301
Appearance
Interface	1*RF interface
	1*100/1000Mbps Adaptive Ethernet port
	None
Antenna	None
Button	1* Reset button
Power supply	DC 12V/1A
Size	16012532.5mm
Weight	259.2g
RF downlink parameters
Frequency range	North American StandardDOCSIS:88-1GHz European Standard:DOCSIS:108-1GMHz
Bandwith	6-8MHz
Modulation	64,256QAM
Bitrate	30Mbps(64QAM+American Standard:DOCSIS) 43Mbps(256QAMAmerican Standard:DOCSIS) 41Mbps(64QAMEuropean Standard:DOCSIS) 55Mbps(256QAMEuropean Standard:DOCSIS)
Input level	+/- 15 dBmV
Input impedance	75 Ohms
RF uplink parameters
Frequency range	North American StandardDOCSIS:5-42MHz European Standard:DOCSIS:5-65MHz
Bandwith	200/400/800/1600/3200/6400 KHz
Modulation	QPSK,8QAM,16QAM,32QAM,64QAM,128QAM,4U/S
Bitrate	30Mbps(TDMA),35MHz(S-CDMA)
Output level	QPSK:+8-58dBmV 64QAM:+8-54dBmV 32QAM:+8-54dBmV S-CDMA:+8-53dBmV
Protocol
Network	TCP/IP/UDP/ARP/ICMP/DHCP/TP/TFTP/SNMP/HTTP
Application	SNMP V1/V2/V3
Management	Support local WEB login
Environment
Operation temperature	0-40℃
Operation humidity	5-95%RH Non-condensing
