CO2 Laser Power Supply 80W

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Beijing, China

Brand Name:

EFR

Model Number:

PS-80

Beijing EFR Laser S&T Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Beijing, China

Brand Name EFR

Model Number PS-80

Output Power Other, 80W

Output Type Single

Input Voltage Other, AC-220V

Output Voltage DC 40KV

Output Current DC 28mA

Specifications

CO2 laser power supply: good compatibility, special current control technology and performance in frequency.

co2 Laser power supply:

We provide such types as:40W,60W,80W,100W,150W.

Some other advantages of our products:

1 Good compatibility , improve the performance of the machines (we would prefer to offer you the laser tubes and the associated power supply)

2 prolong the life of laser maximum ;

3 high voltage switching mode, easy to light;

4 high lighting efficiency

5 over-current protection.

co2 Laser Power Supply Model PS-80 Technical Parameter.

Input Voltage	Input Voltage	AC220V or AC110V
	AC Frequency	47 -- 440Hz
	Cold surge current	≤60A(AC220V input)	≤60A(AC220V input)
	Leak current	≤0.7mA(AC220V input)	≤0.7mA(AC220V input)
Output	Max output Voltage	DC 40KV
	Max Output current	DC 28mA
Efficiency	when>92% load down
Time no-failure	>10000 hours
Response speed	≤1ms(the time from output of switch signal to 90%of initial setting current)
Control port	TTL electricity level switch control, valid electricity has high/low level choices
Voltage-resisting	Input-Output ,input-machine hull: 1500V 10mA 60s AC output cathode and machine hull connection
Protection	Can be used an opening way in a short timerequest the outer shell be good to connect the ground avoid arcing between anode and machine hull connection in the machine
Usage environment	Work temperature(-10 -- 40).Relative humidity≤90%
Cooling Type	The compulsive air cooling
size	L×W×H=320×205×95 mm
