CO2 Laser Power Source

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Beijing, China

Brand Name:

EFR

Model Number:

PS-100/150

Beijing EFR Laser S&T Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Beijing, China

Brand Name EFR

Model Number PS-100/150

Input Voltage 220V or 110V

Output Voltage DC 50 KV

Output Power 100W-150W

Output Frequency 47 - 440Hz

Output Current DC 38 mA

Characticstics of EFR Power Source for CO2 laserr tubes:

1. Good compatibility;

2. Extending the life of laser tube;

3. Power supply-self has a feedback port,can be used for closed-circule control,also can be

used for checking practical operating current of laser tubes;

4. Power supply-self has a protection while openning circuit Power supply can be used in

opering circult state in a short time, so avoid to damage power supply while leaking of laser

tube, so can extend the life of laser tube.

Laser Power Source Model PS-100/150 Technical Parameters

Input Voltage	Input Voltage	AC 220V or AC 110V
	AC Frequency	47 Hz to 440Hz
	Cold Surge Current	≤60 A (AC 220V input)	≤60A (AC220V input)
	Leak Current	≤0.7mA (AC220V input)	≤0.7mA (AC220V input)
Output	Max Output Voltage	DC 50KV
	Max Output Current	DC 38mA
Efficiency	when> 92% load down
Time no-failure	>10000 hours
Response Speed	≤1ms(the time from output of switch signal to 90%of initial setting current)
Control port	TTL electricity level switch control, valid electricity has high/low level choices
Voltage-resisting	Input-Output, input-machine hull: 1500V 10mA 60s AC output cathode and machine hull connection
Protection	Can be used an opening way in a short timerequest the outer shell be good to connent the ground avoid arcing between anode and machine hull connection in the machine
Working Environment	Work temperature(-10 degrees centigrade to 40 degrees centigrade).Relative humidity ≤ 90%
Cooling Type	The compulsive air cooling
Size	L×W×H= 350×240×95mm
