Specifications
1.2* 10M/100M + 1*100Base-FX optic port;2.Multi-mode/Single-mode;
3.ST/SC/FC port could be choosen.
FHC2003 1+2 Ports Industrial Ethernet Converter
Product description
The FHC2003 has 2 ports 10M/100M and 1 port 100Base-FX optic port high performance auto-negotiation industrial
Ethernet fiber optic converter, which is used to Ethernet signature communication.
Specification
Port | |
Port type |
2 10/100 Base-TX port + 1 100Base-FX |
Twisted-pair |
RJ45 port, 10/100Base auto negotiation speed and auto MDI/MDI-X connection |
Fiber optic port |
Multi-mode/Single-mode, ST/SC/FC port could be choose |
Communication distance | |
Twisted-pair |
0~100m |
Fiber optic line |
100Base-FX: multi-mode: <5km; Single-mode: 20km40km60km80km 1000BaseT: multi-mode: 500M; Single-mode: 10km/40km/80km |
Power supply | |
Input Voltage |
24VDC:18-36V 48VDC(customer order) AC/DC:AC85-265V/DC110-370V |
Watt loss |
<5W |
Environmental Limits | |
Operating |
Standard Models: -35°C~75°C |
Temperature |
Storage Temperature: -40°C~85°C |
Ambient Relative Humidity |
0~95%(non-condensing) |
Physical Characteristics | |
Dimension |
144mm×33mm×97mm |
Installation |
DIN-Rail |
Weight |
0.5kg |
Case protection grade |
IP40 |
Package |
IEEE802.3u,IEEE802.3x,IEEE802.3 |
Application
Order Information
FHC2003-P |
2 10/100 Base-TX port 2 10M/100M adaptive port,1 Multi-mode 100Base-FX port,2km |
FHC2003-S-20 |
2 10/100 Base-TX port 2 10M/100M adaptive port,1 Single-mode 100Base-FX port,20km,DC24V |
FHC2003-S-40 |
2 10/100 Base-TX port 2 10M/100M adaptive port,1 Single-mode 100Base-FX port,40km,DC24V |
FHC2003-S-60 |
2 10/100 Base-TX port 2 10M/100M adaptive port,1 Single-mode 100Base-FX port,60km,DC24V |
FHC2003-S-80 |
2 10/100 Base-TX port 2 10M/100M adaptive port,1 Single-mode 100Base-FX port,80km,DC24V |
FHC2003-S-100 |
2 10/100 Base-TX port 2 10M/100M adaptive port,1 Single-mode 100Base-FX port,100km,DC24V |
