Special features
l Main services:1GE+3FE+1VOIP+1WIFI
l Plug and play, integrated technology of auto detecting, auto configuration, and auto firmware upgrade.
l Integrated technology of OMCI, TR069 remote configuration and maintenance.
l Support flexible QinQ VLAN, DHCP Server/Relay and IGMP/MLD multicasting and monitoring.
l Support fiber transceiver diagnostic monitoring, fiber transmitter remote disable.
l Fully compatibility with OLT of Huawei, Fiberhome, ZTE, etc.
l Support 802.11n WiFi (T/R) function.
l Support NAT, Firewall function.
l Support IPv4 and IPv6 dual stack.
l Port’s Integrated circuits testing complies with GR-909.
l The WAN port supports bridge, router and bridge/router mixed mode.
Technical items |
Descriptions |
Optical interface |
1 EPON interface, SC single mode/single fiber, symmetric 1.25 Gbps |
Optical Wavelength |
Tx 1310nm, Rx 1490nm |
Interface connector |
SC/PC |
RX sensitivity |
<-27dBm (1490nm) |
WLAN |
Compliant with IEEE802.11b/g/n, 300Mbps one internal antenna |
LAN interface |
1*10/100Mbps+3*10/100/1000Mbps Auto adaptive Ethernet interfaces, Full/Half Duplex, RJ45 connectors |
Throughput capacity |
Up to 900Mbps and more |
POTS interface |
1FXS, RJ11 connectors |
DC power supply |
12V 1.5A, external AC-DC power adapter |
Button |
Reset, Power, WiFi |
Power consumption |
≤ 10W |
Operating condition |
Operating temp: -5 ~ +55℃,Operating humidity: 10~90% (non-condensed) |
Storing condition |
Storing temp: -30 ~ +60℃,Storing humidity:10~90%(non-condensed) |
Dimension |
185mm*145mm*50mm(L*W*H) |
Net weight |
≤0.4Kg |
Data Service Functions
1) Full speed 1G non-blocking interchange.
2) 2048 MAC address table.
3) 16 VLAN IDs
4) Support VLAN QinQ, transparent, tag, translation, trunk, etc.
5) Integrated port monitoring, port mirroring, port rate limiting, port SLA, etc.
6) Support auto polarity detection of Ethernet ports (AUTO MDIX).
7) Integrated IEEE802.1p QoS with four level priority queues.
8) Support IPv4 IGMP snooping and IPv6 MLD snooping.
POTS Service Functions
1) Support SIP protocol
2) Support H.248 protocol
3) SIP protocol: Provided by the ISP, the port number of communication between SIP proxy server and VOIP terminal. It ranges from 1 to 65535, the system defaults is 5060.
4) H.248 protocol: Provided by the ISP, the port number of communication between alternate MGC and VOIP terminal. It ranges from 1 to 65535, the system defaults is 2944.
5) Port ringing voltage: 50±10VAC, 30±10H
6) Port type is POTS(VOIP)
7) Support voice coding/compression G.711 A-Law/u-Law,G729A/B,G.723.1-5.3/6.3,G.726 etc.
8) Support standby software interchange and auto switching
WiFi service
1) Integrated 802.11b/g/n, 300Mbps.
2) Support 64 connections.
3) Support WEP and WPA/WPA2 security protocols.
