Home > Consumer Electronics > LED Display > Indoor LED Display > Led Electronic Display Screen p6

Led Electronic Display Screen p6

Name: Led Electronic Display Screen p6
Brand: ryham
SKU: 110620289
Availability: InStock

Led Electronic Display Screen p6 thumbnail-1

Led Electronic Display Screen p6 photo-1

US$ 10 - 3,000 MOQ: 2 Square Meters

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

ryham

Model Number:

Contact Supplier Request Quote Chat Now

Shenzhen Ryham Optoelectronics Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name ryham

Model Number p6

Usage Outdoor

Tube Chip Color Full Color

Display Function Video

Pixels Other, 6mm

Screen Dimension 2x2m

led electronic display screen p6

specification:

Item	P6
Pixel pitch	6 (mm)
Pixel configuration	1R1G1B 3in1
Pixel density	27777 pixels/sq.m.
Brightness	≥5000cd/m²
Weight	25-30kg/sqm
Module pixel	32*16 dot
Module dimensions (W×H)	192*96 (mm)
Module dimensions (W×H)	7.7*3.8 (Inch)
Cabinet Resolution	96*96 dot
Cabinet dimension	57657678mm
Refresh rate	≥2000 Hz
Gray scale	65536
Colors	281 trillion
Viewing angle (H/V)	120/80 (deg)
IP rating (Front/Rear)	IP65/IP54
Power consumption (max/avg)	600/300 (W/sq.m.)
Drive mode	1/4 constant current static
Input voltage (AC)	100V ~ 240V
Operating temperature	-20°C ~+ 40°C
Operating humidity	10% ~ 85%
Source compatibility (with video processor)	VGA, DVI, HDMI, SDI
Control distance	Network Cable≤100m, Multimode optical fiber≤500m, Single mode optical fiber≤20 kilometer

Features:

1,P6 outdoor led display screen cabinet weight is only 8.15 kg, depth 75 mm, decreasing the transportation cost and the intensity of labor.

2,P6mm outdoor led display screen with quiet fan design, excellent heat dissipation, noiseless. Quick locks connecting cabinets, only 10 seconds per cabinet.

3,High polymer flexible mask, no dazzle, better contrast ratio; the masks can be pulled off directly from the cabinet, which makes the maintenance much more convenient.

4,High-performance aluminum cabinet, which could bear the weight of 20 cabinets in a vertical line. Louver window design, dust proof & excellent heat dissipation.

5,With intelligent control LCD monitor, easy to know the correct accumulated working time. Pop out back door, much more convenient for the examination and maintenance.
