CLT's total rental solution
The cabinets from part of CLT's total solution, which includes sturdy flight cases, rugged rental structures.
rugged rental cabinets come with rugged rental structures, which allow to be clicked together simply and quickly to form a seamless displyay in no time Easy set-up and tear-down with its specially engineered truss beams, CLT's LED displays are purpose built for fast, easy set-up and repeated relocations
Fully cross-rentable As part of CLT's total rental solution, the cabinets are fully cross-rentable, allowing you to maximise the return on your investment
Ph6mm 3-in-1 SMD indoor full-color LED display
Item |
Parameter |
|
||||
Pixel |
Physical pixel pitch: 6 mm |
|||||
Pixel configuration: 1R1PG1PB |
|
Chip |
Wave |
Brightness |
Packing |
|
R |
Opto |
620-625nm |
300mcd |
SMD-3528 |
||
G |
Silan |
520+/_1.25nm |
850mcd |
SMD-3528 |
||
B |
Silan |
470+/_1.25nm |
180mcd |
SMD-3528 |
||
Module |
Module resolution: 32 x 16 pixels |
|
||||
Module size: 192 x 96 mm | ||||||
Cabinet |
Physical resolution: 128 x 128 pixels |
|||||
Cabinet size: 768 x 768 x 150mm | ||||||
Physical density:16384pixels/cabinet | ||||||
Module quantity: 32pcs= 4(w) x 8(h) | ||||||
Material: Mild steel | ||||||
Weight: 26Kg | ||||||
Average power consumption: 500W | ||||||
Max power consumption: 920W | ||||||
Electricity parameter |
Brightness: 2000 - 2300 nits |
|||||
Brightness adjusted: 100 grade by software, or by Auto-optic induced | ||||||
Color processing: 16bit | ||||||
Display color: 280 trillion | ||||||
Color temperature(k): 5000 — 9500 (choice by user) | ||||||
Physical density: 27777 pixels/m2 | ||||||
Whole display flatness: ≤ 1mm juncture | ||||||
Best view distance: ≥ 5m | ||||||
Best view angle: Horizontal ±80°, Vertical ±80° | ||||||
Storage temperature: -35°C ~ +85°C Working temperature: -20°C ~ +50°C | ||||||
Driving method: Constant driving current Scan: 1/8 | ||||||
Refresh frequency: 2400Hz(Zdec) ≥ 300Hz(Linsn) | ||||||
Frame rate: ≥ 60Hz | ||||||
Humidity(RH): ≤ 90~95% | ||||||
Protection grade: IP64 | ||||||
Working Voltage: DC 5V | ||||||
Power supply: AC 110 / 220V, 50/60Hz | ||||||
Average power consumption:800w/m2 | ||||||
Max power consumption: 1500w/m2 | ||||||
MTBF: 10, 000 hours | ||||||
Screen lifetime: 100, 000 hours | ||||||
Control system |
Control system: Linsn / Zdec |
|||||
Signal interface: DVI | ||||||
Communication distance: Internet cable: ≤120m / Fiber cable: 1000m | ||||||
Signal transfer mode: Pixels to pixels display synchronized | ||||||
CLT - Largest SMD display manufacture in China
Supplier for LED display facotries, distributors and wholesales etc
Products cover both Outdoor and Indoor application
Welcome to CLT, for each customer we'll assign a professional Engineer to support from pre-sale, production and post-sale.
Our Engineer could setup any screen all over the world by internet in our office.
CLT, Your right choice.
Contact us now.
