Help CenterHigh Power COB 10W LED Flood Light,220V Advertising Lamp
Related Products
-
Outdoor IP65 Waterproof LED Flood Light COB 160WUS$ 10 - 200MOQ: 1 Piece -
COB 180W LED Flood Light BG-742-W-180WUS$ 100 - 400MOQ: 1 Piece
-
COB 180W LED Flood Light IP65US$ 100 - 400MOQ: 1 Piece
-
High Power LED Flood Light IP65 60WUS$ 10 - 200MOQ: 1 Piece
-
High Power IP65 60W LED Flood Light Shenzhen Factory Directly SaleUS$ 10 - 200MOQ: 1 Piece
Specifications
10W LED Flood Light1.Input Voltage:AC100-240V
2.Color:White/Warm White
3.Beam Angle:60/120
4.IP Grade:IP65
COB High Power 10W LED Flood Light
LED Flood Light Factorer:
1 .Using self-packaged single 10W-200W High Power LED as the light source. This light source using multi-chip integrated single-group design, select high imports of semiconductor chips, with the feature of high thermal conductivity, small optical decline, pure light color, no ghosting;
2.The LED directly close with the shell, it can scatter heat through the shell and air convection, the shell using aluminum alloy die-casting, the lamp can be effectively scatter heat and ensure the light source life. The perfect combination of 5mm tempered glass with high-intensity lights make the lamps can be using at high-humidity environment;
3. The body using anti-aging sealed silicone rubber, the surface of lamp have done the anodic oxidation and the spray treatment, the overall lighting is in line with the IP65 standard.
LED Flood Light Fixture Technical Parameter
Input Voltage |
AC85V~265V |
|||
Frequency Range |
50Hz~60Hz |
|||
Total Harmonic Distortion |
≤ 9 % |
|||
Power Factor |
>0.98 |
|||
Power Efficiency |
>90 % |
|||
LED Working Voltage |
DC30~36V |
|||
The qty of led |
1 pc |
|||
Led Consumption |
10W |
|||
System Consumption |
11 W |
|||
Led Luminous Efficiency |
80-100 Lm /W |
|||
Led Initial Flux |
960 Lm |
|||
lamp’s Efficiency |
>91 % |
|||
|
Average Luminance |
2 M |
94 LUX |
||
3 M |
42LUX |
|||
4 M |
24 LUX |
|||
|
Luminance Area |
2 M |
The irradiation Are is a circular with 5.5M Diameter |
||
3M |
The irradiation Are is a circular with 8.0M Diameter |
|||
4M |
The irradiation Are is a circular with 10.5M Diameter |
|||
Luminance Uniformity |
>0.6 |
|||
Color Temperature |
Detail information refer to above LED parameters table |
|||
Color Rendering Index |
Ra>80 |
|||
Light Distribution |
symmetric expression / circular light spot |
|||
Light Design |
LED +The reflectors second light distribution |
|||
LED Junction Temperature |
≤80°C |
|||
Working Temperature |
-40°C ~ +55°C |
|||
Storage Temperature |
-25°C ~ +65°C(25°Cis the optimal) |
|||
IP Grade |
IP65 |
|||
Net weight |
0.9 Kg |
|||
Working Life-span |
50000H |
|||
Power line |
1mm2three-core cord
|
|||
Connect wire |
Brown |
L |
||
Blue |
N |
|||
Yellow/Green |
G |
|||
The color of the lamp shell |
black & Silver-White |
|||
certificate |
CE ROHS |
|||
