KBB manual revolving door project
Project name : Hotel Novotel .
Location: Mexico.
Hotel Novotel is a four star hotel in Mexico, lacated in the center of advanced residence and business district, it's very suit for business trip or family holiday .One of KBB manual revolving door was installed in this hotel.
Detailed Information is as follows .
Manual revolving door is one of KBB best selling revolving doors, they are welcomed so well by the hotels, office buildings, shopping mall etc.
Safety functions:
1, Special Load-Bearing Structure
2, Vertical/horizontal safety switch
3, Anti-squeeze
4, Anti-strike
5, Force-sensitive Control
6, Torque Control
7, Panic breakout system
8, Handicap
9, Night Security Door.
Operation features:
1, Continuous working mode
2, Go/Stop working mode
3, Remote control function
Technical Data:
Power supply : 220VAC±10%,50HZ
Rated current :12VAC,50HZ
Rated power : 600W
Down lights : 400W
High speed adjustment range(revolving door) : 1-4r.p.m.
Low speed adjustment range(revolving door) : 0.5-1.5 r.p.m.
Ambient temperature : -30.C – 45.C.
Max relative humidity : 90%.
Total weight <1000Kg
Operating noise ≤ 60db (A)
Specifications:
Inner Dia(D) |
1800mm |
2100mm |
2400mm |
2700mm |
3000mm |
3600mm |
Outer Dia (DT) |
1880mm |
2180mm |
2480mm |
2780mm |
3080mm |
3680mm |
Clear height |
2300mm |
2300mm |
2300mm |
2300mm |
2300mm |
2300mm |
Canopy height |
300mm |
300mm |
300mm |
300mm |
300mm |
300mm |
Total height |
2600mm |
2600mm |
2600mm |
2600mm |
2600mm |
2600mm |
Key Components:
1, Main control unit - SIEMENS
2, Operation program software – KBB
3, Transducer - SIEMENS
4, Drive unit - SIEMENS
5, Gear box - Sewdrive
6, Deceleration belt – CONTITECH
7, Spot light – PHILIPS
8, Detection radar - BEA, Infrared
9, High precision speed/position radar – HENGSTLER
10, Emergency stop button – KBB
11, Handicap button – KBB
12, Curved glass – YAOPI
13, Planar glass – YAOPI
14, Aluminium frame profile - JIHUA
