Specifications
fanch cnc plasma cutting machine /China plasma power source/DSP controller/Taiwan square rails/water jet systemfanch cnc plasma cutting machine /China plasma power source/DSP controller/Taiwan square rails/water jet system
Scope of application:
CNC plasma engraving machine is an automatic and high efficiency engraving equipment. It is widely used in all kinds of carbon materials, stainless steel and nonferrous metal precision sheet metal cutting.
Features of machine:
The beam uses light structural design, with good rigidity structure, light deadweight and small movement inertia.
The gantry structure, Y axis used dual-motor dual-driven system, X, Y, Z axis all use dual-straight rail that make the machine driving smoothly with high-precision.
Aiming at cutting three dimension LED character, trough metal panels and floor cutting, the accuracy can reach good indicators. If it equipped with China 100A plasma source the machine can reach threshold.
Equipped with other advertise equipment (blister machine, engraving machine), forming the advertising word processing pipeline. Completely solve the traditional manual processing methods. Improve the efficiency of several times.
Cutting mouth is small, tidy, and avoids a second dressing processing.
It can apply to iron sheet, the aluminum sheet, the galvanized sheet, hundred steel plates, metal plates and so on.
High cutting speed, high precision, and low cost
The numerical control system disposes high, the automatic striking arc, the performance is stable.
Support Wentai, Astronautics Haire, ARTCAM softwares, Type3 produce standard G code way document, also can change software to read AUTOCAD softwares produce DXF form documents. The control system uses the U-disk exchange processing document, easy to operate.
FC-1325AT performance Parameter
Working area |
1300mm*2500mm |
Working thickness |
0.5-25mm,quality cutting thickness 0.5-10mm |
Cutting speed |
100-8000mm/min |
Power |
8.5kw |
Input voltage |
3(phase)380V |
Power frequency |
50HZ |
Plasma current |
100A |
Interface |
USB |
Work mode |
Untouched arc striking |
Control system |
DSP |
