Specifications
4 axis cnc router with super big diameter /heavy duty structure/4.5kw spindle/AC servo/350mm diameter4 axis cnc router with super big diameter /heavy duty structure/4.5kw spindle/AC servo/350mm diameter
MACHINEFEATURES
1 .Unique four-axis linkage design can automatically process complex polyhedron.
2 .Domestic big power water-cooled spindle motor/imported Italian spindle motor,hign precision,long life,smooth operation,and good startup performance,big torque,and can give full play to the advantages of this machine’s high-speed and efficiency.
3 .Overall thick steel bed , heavy square table support structure , science welding , non-deformed , high-precision gantry milling wholistic processing.
4 .Standard industrial design,the whole machine’s connected parts are all industrial cast aluminum to ensure the machine tool service life.
5 .25MM imported linear guide,double rows and four lines of ball sliders,heavy loading capacity, smooth operation, high accuracy,and the high-strength high-quality steel rails ensure the mechanical accuracy and wearability,rail service life is 10 times higher than the circular rail;
imported high precision ball screw,high accuracy under the knife.
6 .Patented special design of Z -axis industrial level dust preventation,so that protect the Z -axis rail and rack from dust and flakes.
7 .Adopts high-performance 4 axes control system,with excellent and stable quality,good maintenance,you can control the complete multi-level 4D processing,can be fast,smooth three-dimensional machining,engraving and cutting.
8 . Good software compatibility,compatible with type3/Artcam/Castmate/UCANCAM and other CAD/CAM designed softwares.
9 . Vacuum adsorption is made of engineering plastic plates,high adsorption,high-power vacuum pump,can strongly hold different size materials,high den.
Performance parameter:
Feeding height |
400mm |
Work table area |
350x2000mm |
Repositioning Accuracy |
0 .025mm |
Spindle power |
4 .5KW(option) |
Work voltage |
380V/50Hz |
Running speed |
30m/min |
Spindle rotation speed |
6000-24000rpm/min |
Cutter diameter |
¢3 .175 ¢4 ¢6 ¢ 12.7 |
Engraving dictate |
G code,uoo,mmg,plt |
Work style |
stepper (servo optional) |
Sample
