DMX Master Controller With Internal Program as Master

DMX Master Controller With Internal Program as Master thumbnail-1
DMX Master Controller With Internal Program as Master photo-1
US$ 10 - 15 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
BRIGHT
Model Number:
BG-DMX512 -Master
Contact Supplier Request Quote Chat Now
Shenzhen Bright Technology Industrial Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SZ
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin China
Brand Name BRIGHT
Model Number BG-DMX512 -Master

Specifications

DMX Master Controller
1. DMX Signal Output
2. have 48kinds internal program
3. RF Remote
4. DC input

DMX LED Controller with Internal program as Master





DMX LED Controller  adopts the advanced micro control unit, as a DMX512 master controller, It can send

the DMX-512 standard digital control signal which is internationally widely used.Connection with DMX decoder, the decoder can be increased to continue to expand output channels,To achieve the effect of multiple point changes.For example: synchronous static, jumpy changing, gradual changing, stroboflash and other effects of change.



Technical Parameters

Working temperature

-20-60°C

Supply voltage

12V~24V

Output DMX512 signal

1 channel

0utput PWM

3 channels

Output current

<4A(each channel)

Output power

12V:<144W,   24V:<288W

Connecting mode

common anode

External dimension

L130ΧW70ΧH24 mm

Packing size

L137ΧW80ΧH54 mm

Net weight

260g

Gross weight

280g

Frequency of RF remote control

433.9MHz

Frequency of PWM signal output

120Hz

Slave numbers

255

Internal Program for Choosing.

Items

Patterns

Remarks

Items

Patterns

Remarks

1

Static red







Brightness is adjustable, Speed is unadjustable.

25

White head on collision

Brightness is adjustable, Speed is adjustable.

2

Static green

26

Red breathing lamp to forward direction

3

Static blue

27

Green breathing lamp to forward direction

4

Static yellow

28

Blue breathing lamp to forward direction

5

Static purple

29

Yellow breathing lamp to forward direction

6

Static cyan

30

Cyan breathing lamp to forward direction

7

Static white

31

Purple breathing lamp to forward direction

8

Red stroboflash

Speed and Brightness

are adjustable

32

White breathing lamp to forward direction

9

Green stroboflash

33

Red breathing lamp to backward direction

10

Blue stroboflash

34

Green breathing lamp to backward direction

11

Yellow stroboflash

35

Blue breathing lamp to backward direction

12

Purple stroboflash

36

Yellow breathing lamp to backward direction

13

Cyan stroboflash

37

Cyan breathing lamp to backward direction

14

White stroboflash

38

Purple breathing lamp to backward direction

15

Three-color jumpy changing

39

White breathing lamp to backward direction

16

Seven-color jumpy changing

40

RGB 3 colors trail to forward direction

Speed is adjustable, Brightness is unadjustable

17

Three-color gradual changing

Brightness is unadjustable, Speed is adjustable.

41

RGB 3 colors trail to backward direction

18

Seven-color gradual changing

42

Red forward stack

Speed and Brightness

are adjustable

19

Red horse race lamp forward direction

Speed and Brightness

are adjustable

43

Green forward stack

20

Green horse race lamp to forward direction

44

Blue forward stack

21

Blue horse race lamp forward direction

45

Red backward stack

22

Red horse race lamp backward direction

46

Green backward stack

23

Green horse race lamp to backward direction

47

Blue backward stack

24

Blue horse race lamp backward direction

48

Automation

1~47

Application





DMX Master Controller with Internal program as Master
