I. Summarize
Welcome to use LED WiFi Controller, this controller is designed for low voltage(12V-24V) light, such as 12V LED strip,12V panel light etc. After installation and settings,your phone (IOS or Android system) can control light directly. The remote control distance reachs 50 meters indoor and more than 100 meters outdoor
II. Specifications
(A) RGB/RGBW,16 million colors, built-in 20 dynamic models,DIY models,music modes
(B) divide into groups function
(C) timing function, automatic turn on/off as your setting time. Set any dynamic models
(D) allocate to router by one key”WPS”
(E) after connecting router,controller’s wifi signal will be hided automatically to prevent hotlinking
(F) memory function,keep same status as last time after power off
(G) single control by phone or integrated control by router
(H) operating platform:requires Android 2.3.3 or later,IOS 6.0 or later
III. Technology Parameter
I.01 Data Parameter
l Input voltage:DC12V-DC24V
l Power:DC12V:192W;DC24V:384W;
l Application:common anode,constant voltage light,such as 12V LED strip,12V LED panel light etc
l Output currrent:4A*4
l Connection:common anode
Input:(wire terminal or DC head )
V+: connect anode of power supply
V-: connect cathode of power supply
Output:
V+:connect anode of lamp
R:connect anode of red color
G:connect anode of green color
B:connect anode of blue color
W:connect anode of white color if you light have this port.
I.02 Software User Manual
l Android:
l Name:Magic UFO -WiFi Controller
l Running platform:requires Android 2.3 with wifi function or later
l Language:Chinese/English,app shows same language as your system’s in default
l IOS:
l Name:Magic UFO-WiFi
l Running platform:requires ISO 6.0 or later
l Language:Chinese/English,app shows same language as your system’s in default
Product Pictures
Package
Other Series Controller;RF/IR/2.4G,etc
1. Shipping by EMS, DHL, UPS, FedEx, sea shipping and air shipping according to customers' requirement;
2. Normal delivery time: 7-10 working days.
3. Packing:Standard export packing box.
1. Your inquiry will be replied within 12 hours;
2. Any question during using ,we always reply in time;
3. All products are tested and packed well before delivery;
4. We will arrange the fast shipping for you;
5. Your private information will be well protected.
1. Competitive price;
2. Our products are under strcit quality control ;
3. Large producing capacity : 80,000pcs/month;
4. Any quantion willbe replied as soon as possible.
5. Professional LED light supplier with more than five years experience;
Bright Technology Industrial Limited is a Hi-tech enterprise specialized in LED industry, which integrates research, producing, selling, post-sell service and so on. We have an experienced technology team and marketing group. Technology is key to energy saving. Bright Technology is persisted in researching and developing new technology for the LED products applied in different conditions. Currently, we have a series of independent patent and know-hows on LED lights,including LED strip,LED spotlight, ceiling light, LED down light, and LED bar light, etc. We have thousands of products sold to the world market and we establish business relationship with many countries over the world.
