1000w Solar Powere System

Name: 1000w Solar Powere System
Brand: jiuhua
SKU: 110577901
Availability: InStock

US$ 100 - 1,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

jiuhua

Model Number:

1000w-3000w

Jiangsu Jiuhua Energy Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

ningbo

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name jiuhua

Model Number 1000w-3000w

Specification Mini

Application Home

Output Voltage (V) 220v/110v

Load Power (W) 1000w-3000w

Solar Power (W) 1000w-3000w

Work Time (h) 20hrs

Specifications

long lifetime5-10years
mini system
easy installation
competive price
ac solar system

Product Features	Suitable Places
220v/110v output	All areas without electric power supply
220v/110v Output	where power cut happens often
Charging and discharging status shown by LCD display	Field work or suburb temporary office
Input, output with safety protection function	In Island and fishing
Easy machine operation and mounting installation	Border post, nomad tents
Particular charge controller keep the batteries regulated with high efficiency and longer running hours	Night market business
Moderate weight and easy to carry	Sight spot

Technical data and specifications:

Model	G004
AC voltage	AC220V±5% Two connector
Rated power	1000W	2000W		3000W
Surge power	1500W	3000W		4500W
Wave and frequency	Pure wave 50HZ±1%	Pure wave 50HZ±1%		Pure wave 50HZ±1%
DC output	DC24V(other)	DC48V(other)
Charging voltage	34.4V	68.8V
Main machine shell	zine coated and anti-corrosin steel
Display Type	LED screen display working status of charging and discharging and battery
Solar charger controller	40A/24VSolar charger controller		50A/48VSolar charger controller
Battery	Solar gel or Lead-acid battery 12V200Ah*2		12V200Ah*4
Solar panel wattage	185W*4(standard)According to need to increase or decrease
Environment	relative humidity:-20 ºC ~60ºC relative humidity:95%
dimension of machine	610X330X1100mm	610X600X1400mm
dimension of packaging	700X400X1200mm	700X700X1500mm
Machine net weight	30Kg(without battery)	70Kg(without battery)
Machine net weight	150Kg (with battery)	310Kg (with battery)
Elevation limit	<6000m
Other	Automatic switching between solar and utility power; Mounting system

An example of type and quantities of loads to be supplied

(under standard test conditions (STC) of irradiance of 1000W/m²)

Electric power generated W/day	4440W(740W Panel)
Capacity of electric power storage W	4800W(200Ah/24V)
Appliance equipment	Running Hours
1P air conditioning 800W	4h
desktop computer 120W	28h
LCD TV 100W	34h
washing 250W	13.5h
