Specifications
12v 24v rigid led bar,60leds/m led bar with CE RoHsDC12V
Viewing angle:120degrees;
life: 50,000 hours;
Color:white
12v 24v rigid led bar,60leds/m led bar with CE RoHs
Features:
1.Work voltage DC12V/24V
2.Standard length: 60led/pcs
3.PCB Width:10mm,
4. Available Color: White, Warm White, Red, Green, Blue, Yellow,RGB
5.SMD5050LEDs,60LEDs/meter.,72led per meter
6.Beam Angle: 120 degree.
7.Light decay: Less than 5% after 1000 hours constant work.
8.Protect range: non-waterproof or waterproof IP65. Can be waterproof with nanomaterials coating.
9.Life Span: 50,000-80,000 hours
Specifications
Product NO. |
LED TYPE |
LED Qty. |
Voltage |
Current |
Luminous Flux(lm) |
Power |
Color |
PCB Material |
IP Grade |
View Angle |
Size:mm |
BG-1701-3528-60 |
SMD3528 |
60Pcs/m |
12V DC |
0.4 A |
300-350 |
9.6 W |
Single color |
FR-4 |
No |
120° |
1000*8*4 |
BG-1702-3528-60 |
SMD3528 |
60Pcs/m |
12V DC |
0.8 A |
290-335 |
9.6 W |
Single color |
FR-4 |
No |
120° |
1000*10*7 |
BG-1702A-3528-60 |
SMD3528 |
60Pcs/m |
12V DC |
0.8 A |
275-325 |
9.6 W |
Single color |
FR-4 |
IP65 |
120° |
1000*10*7 |
BG-1703-5050-60 |
SMD5050 |
60Pcs/m |
12V DC |
1.2 A |
840-870 |
14.4W |
Single color /RGB |
FR-4 |
No |
120° |
1000*12*4 |
BG-1704-5050-60 |
SMD5050 |
60Pcs/m |
12V DC |
1.2 A |
830-860 |
14.4W |
Single color /RGB |
FR-4 |
No |
120° |
1000*12*7 |
BG-1704A-5050-60 |
SMD5050 |
60Pcs/m |
12V DC |
1.2 A |
810-840 |
14.4W |
Single color /RGB |
FR-4 |
IP65 |
120° |
1000*12*7 |
BG-1705-5050-72 |
SMD5050 |
72Pcs/m |
12V DC |
1.45 A |
970-980 |
17.5W |
Single color /RGB |
MCPCB |
No |
120° |
1000*8*4 |
BG-1706-5050-72 |
SMD5050 |
72Pcs/m |
12V DC |
1.45 A |
930-950 |
17.5W |
Single color /RGB |
MCPCB |
No |
120° |
1000*12*20 |
BG-1706A-5050-72 |
SMD5050 |
72Pcs/m |
12V DC |
1.45 A |
910-940 |
17.5W |
Single color /RGB |
MCPCB |
IP65 |
120° |
1000*12*20 |
APPLICATIONS
1.Jewelry counter lighting
2.Indoor decorative lighting and backlighting
3.Emergency hallway lighting
4.Auditorium walkway lighting
5.Indoor/outdoor illuminated signs and advertisements
6.Backlighting for larger size ad-signs
7.Elegant interior decoration
8.Nice accent lighting lamps
9.Landscape outlines, etc.
led light bar picture:
Picture of 5630 led strip:
Picture of 3528 led bar light:
matters needing attention:
1. Supply voltage of this product is 12v; never connect to other high voltage.
2. Never connect two wires directly in case of short circuit.
3.Lead wire should be connected correctly according to colors that connecting diagram offers.
express Delivery:
Any questions, please don't hesitate to contact me, you're always welcome! (Sophie-Tuo)
