warehouse 2.5m small electric hydraulic pallet forklift
warehouse 2.5m small electric hydraulic pallet stacker forklift
warehouse 2.5m small electric hydraulic pallet stacker forklift are designed to operate in narrow passage and limited space, and are ideal facilities to load/unload and stack goods in stacking warehouse, supermarket and workshop etc. these trucks have following features and benefits, human system engineering design, continusous y variable drive, wide view mast assembly made of germang steel, maximum lifting height 6 meters, with optional standing plat.
General |
Model |
Unit |
HL10 |
HL12 |
HL15 |
|
Rated load capacity |
kg |
1000 |
1200 |
1500 |
||
Power |
|
Tractive-type battery |
||||
Operator type |
|
Pedestrian / rider (pedal) |
||||
Characteristics |
Maximum lifting height |
mm |
1600 |
1600 |
1600 |
|
Lowered height of fork |
mm |
≤90 |
≤90 |
≤90 |
||
Minimum turning radius |
mm |
1425 |
1425 |
1650 |
||
Minimum aisle width |
mm |
2300 |
2300 |
2500 |
||
Minimum ground clearance |
mm |
30 |
30 |
30 |
||
Standard fork length |
mm |
1150 |
1150 |
1150 |
||
Standard fork width |
mm |
160 |
175 |
175 |
||
Fork overall width |
mm |
560 |
570 |
570 |
||
Fork individual width |
mm |
240 |
220 |
220 |
||
Chassis |
Overall length |
mm |
1800 |
1800 |
1988 |
|
Overall width |
mm |
850 |
850 |
1000 |
||
Mast extended height |
mm |
1975 |
1975 |
1975 |
||
Mast lowered height |
mm |
1975 |
1975 |
1975 |
||
Performance |
Maximum traveling speed |
Laden |
km/h |
4 |
4 |
4 |
Unladen |
km/h |
6 |
6 |
6 |
||
Maximum lifting speed |
Laden |
mm/h |
80 |
80 |
80 |
|
Unladen |
mm/h |
130 |
130 |
130 |
||
Maximum lowering speed |
Laden |
mm/h |
110 |
110 |
110 |
|
Unladen |
mm/h |
90 |
90 |
90 |
||
Gradeability |
Laden |
% |
5 |
5 |
5 |
|
Unladen |
% |
8 |
8 |
8 |
||
Brake |
Braking type |
|
Electromagnetic |
|||
Wheel |
Wheel type front/rear |
|
Poly/Poly |
|||
Wheels |
|
1×Driven wheel,2×Balance wheel,4×Front wheel |
||||
Balance wheel dimension |
mm |
Φ156×50 |
Φ156×50 |
Φ156×75 |
||
Axis space |
mm |
1228 |
1228 |
1450 |
||
Motor |
Driving motor |
kw |
1.2 |
|||
Lifting motor |
kw |
2.2 |
||||
Battery |
Battery(Voltage/Capacity) |
V/Ah |
12/120×2 |
12/165 |
24/210 |
|
Control |
Control system |
|
Curtis I207a |
|||
Weight |
Weight |
kg |
650 |
690 |
690 |
|
this paramter only for reference,we provice 1600mm-6000mm and load 1000-2000kg stackers,please contect me,if you have nterest.
