Semi Electric Straddle Stacker

Semi Electric Straddle Stacker thumbnail-1
Semi Electric Straddle Stacker photo-1
US$ 1,200 - 3,200 MOQ: 2 Sets
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
Jetstar
Contact Supplier Request Quote Chat Now
Taizhou Jetstar Machinery Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Jiangsu, China
Brand Name Jetstar
Model Number CTD
Type Powered Pallet Truck
Power Souce DC Motor
Rated Loading Capacity 1500kg
Max. Lifting Height 90mm
Min. Lifting Height 3500mm
Fork Length 1000
Fork Width 160
Overall Dimensions 1780*850*2350
Certification CE,ISO
After-sales Service Provided Engineers available to service machinery overseas

Specifications

semi electric straddle stacker
easy to operate
with high performing
The adjustable leg and fork design for low pallet

Semi electric straddle stacker



The main features of this semi electric straddle stacker is small volume, light weight, pollution free, low noise, easy operation, convenient maintenance and low costs. It brings benefits for enterprises and quiet for environment.

Because of its small volume, light weight, it is fitted for narrow passage way, floors and those working sites with complicated environment and even it is a ideal tool for transportation in such areas as containers, cabin, carriage, and bus stations, etc.

It can be used as unit transportation in the work shop, thus, it raised moving efficiency and reduces labor intensity in a great extent.The rated lifted quantity is 1~2T and rated lifting height is 1.6~3.3m. There are lots of kinds and the fork includes fixed type, flexible type, forging type and wide landing leg.

  • Super-thin body and heavy duty design
  • Operating steady and flexible
  • Low noise,no pollution and reliable performance

Main Configurations

  1. Heavy duty PU Wheel
  2. Imported Pump Station
  3. High-quality design with "C-shaped" mast
  4. Standard type ; Economy Type ; Manual Type

Specification1KG=2.2LB 1INCH=25.4MM





Model Unit CTD10 CTD12 CTD15
Rated load capacity kg 1000 1200 1500
Load center mm 600 600 600
Std.type lifting height (max) mm 1600/2500/2900/3300
Fork min. height mm 90 90 90
Turning radius mm 1370 1370 1420
Fork length mm 350 350 390
Axis space mm 1225 1225 1275
Overall length mm 1725 1725 1775
Overall width mm 870 870 920
Overall height mm 1965/1765/1965/2165
Std.max lifting height mm 1965/2970/3370/3770
Standard fork mm 1000×160×60 1000×160×60 1000×160×70
Fork overall width mm 560 560 560
Fork individual width mm 240 240 240
Lifting speed mm/s 80/130 80/130 80/130
Lowering speed mm/s 110/90 110/90 110/90
Braking type   Foot Braking
Loading wheel dimension   Φ80×70 Φ80×70 Φ80×70
Balance wheel dimension   Φ180×50 Φ180×50 Φ200×50
Lifting motor kw 1.6 1.6 2
Battery(Voltage/Capacity) V/Ah 12/120 12/120 12/150
Weight kg 400/480/510/540 440/510/530/550



Jetstar Semi electric stacker Pictures



Safety & Maintenance

  1. Before the stacker used, completely inspect such aspects as the fixing of battery contact, electricity consumption, flexibility of rotation and leakage of hydraulic station and the electrical connection, etc.
  2. Load the goods in accordance with rated weight of stacker, which is indicated on rated load curve. When the gravity of goods exceeds designed load central distance, reduce the lifting weight according the specified quota. Refer to Fig 2 and technical characteristics and parameter on page 1.
  3. Strictly forbid the super partiality porterage to picks to carry with the single fork, take strict precautions against to turn over the car trouble occurrence. The movable goods fork must guarantee at symmetry position in slippery the center on the poie, then can be in use, will make to turn over the car trouble otherwise.
  4. When operates, person is strictly prohibited standing on fork or on main body.
  5. Carry out maintenance after each shift, including clean the dirty, inspection the fixing of each parts as well as the lubrication of moving parts.
  6. Level 1 maintenance of stacker is made one month later, including daily maintenance, check the work of motor oil pump and oil cylinder, lifting speed and whether there are vibration and blocking situation, if there are abnormal, find out solution timely.
  7. Level 2 maintenance of stacker is made hale year later. Besides the above mentioned items. It is need to replace new hydraulic oil, replace worn sealing parts, lubricate the chain and sliding wheel, regulate the fixing and inspection electrical element, check and see whether the electricity meter and key switch are normal or not. Replace the new one if it is damaged.
  8. Clean off the dirty of chain, chain wheel, rolling wheel and sliding wheel on such parts as moving, rotation and lifting sliding positions, add new oil and lubricate them all the time.

Taizhou Jetstar Machinery Equipment Co., Ltd. (formerly named Nanfang Machinery Factory) is a Hong Kong sole invested company. Our company was established in 1991 as a professional manufacturer and exporter of building machine and logiest machine. As a diversified, high-tech, and internationalized large modern company, our head office is located in Hong Kong, as a window for overseas business. Our factory is located in Economic Development Zone, Taizhou City, Jiangsu Province.
