5630 Led Strip 12000k,aluminum 5630 Bar,1M Aluminum Bar

Shenzhen Bright Technology Industrial Ltd.
5630 Led Strip 12000k,aluminum 5630 Bar,1M Aluminum Bar thumbnail-1
5630 Led Strip 12000k,aluminum 5630 Bar,1M Aluminum Bar photo-1
US$ 1 - 7 MOQ: 1 Meter
Key Specifications
Get Latest Price
LED Light Source:
LED SMD5630
Type:
LED Bar Lights
Input Voltage(V):
DC12V/24V
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
ShenZhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source LED SMD5630
Type LED Bar Lights
Input Voltage(V) DC12V/24V
Lamp Power 24W/m
Lamp Luminous Flux(lm) 2400
Color Temperature(CCT) 2700-7500K
Working Temperature(℃) -20, +60
Working Lifetime(Hour) 50000
Lamp Body Material Aluminum Alloy
Certification CE, SAA, CE
Emitting Color Other, White,Warm White,Cool White, White
Place of Origin Guangdong, China
Brand Name Bright 5630 led strip 12000k
Model Number BG-1707-5630-60

Specifications

5630 led strip 12000k,aluminum 5630 bar,1M Aluminum Bar
1.Voltage:DC12V/24V
2.SMD 5630 LED bar
3.Lumen:40-45Lm/LED

5630 led strip 12000k,aluminum 5630 bar,1M Aluminum Bar
FEATURES

1. Work voltage DC12V/24V

2.Working current ( one meter): 400mA/600mA

3.Standard length: 1meters/pc.

4.PCB Width: 10mm , 12mm

5.Rigid strip, cuttable every 3/6leds.

6.Available Color: White, Warm White.

7.White PCB are available.

8.SMD5630, 60LEDs/meter.

10.Sign chip or 3 chips LEDs are available.

11.Beam Angle: 120 degree.

12.Light decay: Less than 5% after 1000 hours constant work.

13.Protect range: non-waterproof or waterproof IP65.

14.Can be waterproof with silicon cover.

15.Can be waterproof with nanomaterials coating.

16.Life Span: 50,000-80,000 hours.

17.Hight Lumen:2400Lm/m

5630 led strip 12000k,aluminum 5630 bar,1M Aluminum Bar



5630 led strip 12000k,aluminum 5630 bar,1M Aluminum Bar



5630 led strip 12000k,aluminum 5630 bar,1M Aluminum Bar



5630 led strip 12000k,aluminum 5630 bar,1M Aluminum Bar



5630 led strip 12000k,aluminum 5630 bar,1M Aluminum Bar



5630 led strip 12000k,aluminum 5630 bar,1M Aluminum Bar

IP65 Waterproof 5630 LED Bar:

5630 led strip 12000k,aluminum 5630 bar,1M Aluminum Bar



5630 led strip 12000k,aluminum 5630 bar,1M Aluminum Bar



5630 led strip 12000k,aluminum 5630 bar,1M Aluminum Bar



5630 led strip 12000k,aluminum 5630 bar,1M Aluminum Bar

5050 led bar:

Specifications

Product NO.

LED TYPE

LED Qty.

Voltage

Current

Luminous Flux(lm)

Power

Color

PCB Material

IP Grade

View

 Angle

Size:mm

BG-1701-3528-60

SMD3528

60Pcs/m

12V DC

0.4 A

300-350

9.6 W

Single color

FR-4

No

120°

1000*8*4

BG-1702-3528-60

SMD3528

60Pcs/m

12V DC

0.8 A

290-335

9.6 W

Single color

FR-4

No

120°

1000*10*7

BG-1702A-3528-60

SMD3528

60Pcs/m

12V DC

0.8 A

275-325

9.6 W

Single color

FR-4

IP65

120°

1000*10*7

BG-1703-5050-60

SMD5050

60Pcs/m

12V DC

1.2 A

840-870

14.4W

Single color /RGB

FR-4

No

120°

1000*12*4

BG-1704-5050-60

SMD5050

60Pcs/m

12V DC

1.2 A

830-860

14.4W

Single color /RGB

FR-4

No

120°

1000*12*7

BG-1704A-5050-60

SMD5050

60Pcs/m

12V DC

1.2 A

810-840

14.4W

Single color /RGB

FR-4

IP65

120°

1000*12*7

BG-1705-5050-72

SMD5050

72Pcs/m

12V DC

1.45 A

970-980

17.5W

Single color /RGB

MCPCB

No

120°

1000*8*4

BG-1706-5050-72

SMD5050

72Pcs/m

12V DC

1.45 A

930-950

17.5W

Single color /RGB

MCPCB

No

120°

1000*12*20

BG-1706A-5050-72

SMD5050

72Pcs/m

12V DC

1.45 A

910-940

17.5W

Single color /RGB

MCPCB

IP65

120°

1000*12*20

APPLICATIONS

Jewelry counter lighting

Indoor decorative lighting and backlighting

Emergency hallway lighting

Auditorium walkway lighting

Indoor/outdoor illuminated signs and advertisements

Backlighting for larger size ad-signs

Elegant interior decoration

Nice accent lighting lamps

Landscape outlines, etc.

Signal lighting



5630 led strip 12000k,aluminum 5630 bar,1M Aluminum Bar



5630 led strip 12000k,aluminum 5630 bar,1M Aluminum Bar

Express Delivery:

 5630 led strip 12000k,aluminum 5630 bar,1M Aluminum Bar
