High Quality NCB flexo ink printability tester for paper
- 50 Piece / Pieces per Month
- Zhongshan
- Sand Water Filter/Water treatment plants
- Automatic Doypack Seal Machine (insert and sealing machine)
- IEC 62368-1 Figure 49 Aluminium Foil with J type thermocouple
- IEC62368-1 Figure 48 Aluminium Ring with K type thermocouple
- IEC 62368-1 Figure 47 Steel Disc for temperature rise test
- ISO20957-1 Figure 1 Test Finger Φ9.5mm
Product Details
Place of Origin: | Guangdong, China | Brand Name: | Caibang | Model Number: | CB150-Y |
Product Description
1.Our Clients
2.Tech info.
Model No. | CB150-Y |
Application | Single-color proofing (e.g. color matching and testing) |
Power Supply | 220V, 50/60Hz |
Power | 300W |
Inking Method | Ink dropping with burette |
Cleaning | Ultrasonic automatic cleaning |
Applicable Ink | Flexographic water ink, UV ink, lithography ink, relief printing ink |
Thickness of Proofing Material | 0.01-2mm (Flexible material) |
Size of Proofing Material | 150x210mm 150*φ200 |
Applicable Proofing Material | Paper, plastic film, non-woven fabrics, napkin, gold/silver card paper, etc. |
Pressure of Printing Plate Roller and Ceramic Roller | arbitrary adjustment |
Pressure of Printing Plate Roller and Press Drum | arbitrary adjustment |
Printing Speed | Adjustable, 0-48m/min |
Printing Area | 155x220mm |
Area of Printing Plate | 140x150mm |
Thickness of Printing Plate | 1.7MM flexible plate |
Specs of Ceramic Screen Roller | φ70*200MM |
Thread Number of Ceramic Screen Roller | 400, 500 and 600, with a standard roller supplied (70-1,200 available for customization) |
Dimension (L*W*H) | 760x375x365mm |
Net Weight | 125KG |
