reci laser tube factory price co2 laser cutting machine for acrylic
Technical specification:
Model |
QL-1325 |
Effective area |
1300*2500mm |
Laser power |
100w |
Laser type |
10.6um,co2 sealed glass laser tube |
Cooling mode |
Water cooling |
Engraving scanning speed |
0-60000mm/min |
Cutting speed |
0-30000mm/min |
Laser energy control |
1-100% software setting |
Mini-shaping character |
Chinese character2.0*2.0mm,English1.0*1.0mm |
Max-scanning precision |
2500DPI |
Positioning precision |
0.01mm |
Supported graphic format |
DSP PLT BMP DXF AI |
Supported software |
Tiandao embroidery,photoshop,coreldraw,autoCAD |
Division cutting yes or no |
Yes |
power |
AC110V-220V+10%,50-60HZ |
Driving system |
Stepper motor |
Optional configuration |
Lift table,honeycomb table,rotary,double laser heads. |
Product overview:
The belt-module of new materials is adopted in QILI laser engravers,the engravers feature hi-precision,long service life.laser tube is separated from working surface,so it ensures safety of laser tube and cleanness of beam path.all switches,sockets and joints are level with surface of engravers to ensure safety.
Product features:
1.QILI series of laser engraving cutting machines adopt new type,hi-speed laser tube,which make beam more stable than common laser tube,the service life of the laser tube can reach 1000 hours.
2.Compared with common laser engravers,QL series of laser engravers adopt more specific design of machine-body,higher strength steel frame structure,which make strength forty percent more higher,never deformable.
3.Humanized and most modernized design of appearance reflects caring idea of QILI,it is simple to operate and maintenance.
4.Advanced DSP control system and special motion control ship make the machines cut curve continuously and rapidly,the selection function of the shortest path makes efficiency higher.
5.All machined are configurated with U-disk offline control system,so it is more simple and easier to operate.
6.The red-light positioning device can indicate process site of laser head to avoid trouble of manual position.
Scope of application:
Mold industry(building model,air navigation mould,wood mould),advertisement trade,decoration trade,draft gift industry,electrical and electronic industry.
Acrylic,wood plate(cork wood,fortune paulownia wood),bamboo ware,double color plate,paper,leather,shell,coconut shell,ox horn,pitch,ABS plate,lampshade and other non-metal materials.
reply your more doubts before sending inquiry:
1) This is the first time I use this kind of machine, is it easy operate?
There are english manual or guide video that show how to use machine.
If there is still have any question, we can talk from phone or skype.
2)Can you recommend a CNC ROUTER MACHINE to me,thanks?
Yes, In order to give you a suitable router machine, pls tell me the max working area, materials
for processing and the thickness for materials processing engraving or cutting. Then perfect suitable cnc router will be recommended
3) If machine have any problem after I ordered it, how could I do?
Free parts send to you in machine warranty period if machine have any problem.
Free after-sales service life for machine, please feel free contact us if your machine have any problem. we will give you 24hours service from phone and skype.
4) MOQ ?
Our MOQ is 1 set machine. We could send machine to your country port directly, please tell us your port name. There will be best shipping freight and machine price send to you
5)Payment terms
a. 30% by T/T in advance,70% bY T/T before shiping
b. L/C is acceptiable ,if the amount is big,please issue the draft for our confirmation at first.
6)Delivery terms
We will arrange the delivery as the terms we both agreed with after the confirmation by the buyer.
samples made :
the machine photo and spare parts:
certificate :
company and sales team photos:
looking for agents all over the world
