New Product!!!H.264 Network AHD 1080N 1080N Coaxial HD AHD DVR
16CH DVR with 7INCH LCD MONITOR
| VIDEO INPUT (BNC) | VIDEO OUTPUT (BNC) | VGA | AUDIO INPUT | AUDIO OUTPUT | ALARM INPUT | ALARM OUTPUT | HDD QTY | PLAYBACK synchronously MAX | Maximun OF EACH HDD | Maximun OF TOTAL HDD | CMS SOFTWARE | FLASH MEMORY BACKUP | DVD WRITER |
| 16 | 1 | 1 | 6 | 1 | NO | NO | 1 | 16CH | 6T | 12T | YES | YES | NO |
SPECIFICATIONS:
l Support AHD-H series front-end not real-time encoding;
l Support VGA, HDMI HD output;
l Support XM Cloud technology, easy to achieve a variety of network penetration, one step to remote monitoring, getting rid of various complicated network settings, easy and simple to operate;
l Support various mobile monitoring:(IOS, Android).
l Support multiple web browsers(IE,Chrome,Firefox,Safari);
l Support more than 20 languages, no nation boundaries;
l perfect protection circuit, unique triple watchdog function
l Supporting web, CMS, center platform management software MYEYE, provide SDK development.
| Model | AP-D7016A-LM-V2 |
System | Main processor | Hi 3521A |
Video | video codec | H.264 |
| Encode | 16*1080N@12fps |
| Decode | 16*1080N@12fps |
| Onvif | support |
| Multi-mode input | PureAnalog:16*1080N;8*1080N; Mixed:8*1080N (analog)+ 8*960P(network); Pure Network:8*1080P;16*960P;4*3M;4*5M |
Audio | Audio compression | G.711A |
| Intercom | support |
Recording and Playback | Record mode | Manual>alarm>motion detection>timing |
| Playback Channels | 16 (pure local input mode) |
Storage and backup | Backup mode | Network backup,USB HDD, USB writer,SATA writer |
Interface | Video input | 16 BNC |
| Video output | 1ch VGA,1ch HDMI |
| Audio input | 6ch RCA |
| Audio output | 1ch RCA |
| Alarm input | 4 |
| Alarm output | 1 |
| Network interface | RJ45 10M/100M Adaptive Ethernet port |
| PTZ control | RS485; support multiple PTZ protocols |
| USB | 2 USB ports |
| Hard disk | 2 SATA(Each maximum support 6T ) |
| Wireless | 3G,WIFI(expand via USB) |
Other | Power | 12V/4A |
| dimension | 350mm(length)* 296mm(width)* 44mm(height) |
Sunivision has CE & ROHS for both DVR & CCTV CAMERAS.
Sunivision Technology Development Co., Ltd. is a leading and professional CCTV manufacturer located in Guangzhou, China. Sunivision was established in 2008, with 2000 square meter factory and 150 employees including 5 R&D engineers and 10 person for quality control, 15% of the year sales volume will be put into R&D, 2-5 New products will be come out every month.
Sunivision sepcialized in researching, producing and exporting CCTV Analog Cameras, AHD Cameras, Digital Cameras (IP Camera, CVI Camera, TVI Camera etc.) and Stnad-alone DVRs, CVI DVR, AHD DVR, NVR, providing the most stable digital security solutions.
