Newly HOT commercial 4 channel CCTV camera kits home security system
Packing details:
2pcs metal dome camera sony 420TVL 24pcs IR leds (AP-144G)
2pcs outdoor bullet camera sony 420TVL 36pcs IR leds (AP-1474A)
1pc 4CH H.264 DVR with VGA, support mobile monitor (AP-9604HV)
4pcs 20meter(65ft) video+power Cable
1pcs Power supply for 4 camera 12V DC 3A
1pc 1 metre crossed network patch lead
1pc BNC to TV connector
1pc DVR mouse
1pc DVR remote control
4pcs CCTV Sign
Camera Specifications:
MODEL | AP-144G/ AP-1474A |
Image Device | 1/3" SONY |
TV Format | PAL/NTSC |
Number of Pixel | NTSC: 510x492/ PAL: 512x582 |
Resolution | 420 TV lines |
Sync.System | Internal |
IR LED | 24 units IR LEDs |
IR Effective Range | UP to 15 meters |
Minimum Illumination | 0LUX(IR ON) |
LEN | f3.6MM/6MM (F2.0) |
IP Rating | IP66 |
AGC | AUTO |
S/N Ratio | ≥48dB |
Smart Light Control | YES |
Gain Control | Auto |
White Balance | Auto(2500°K~9500°K) |
Electronic Shutter | Auto E Shutter:1/60(1/50)~1/100000 Sec(PAL) 1/60~-1/120,000 Sec(NTSC) |
Back light Compensation | AUTO |
Video Output | 1.0Vp-p composite 75ohm |
Power Consumption | 300mA/350mA |
Power Supply | DC12V |
Operation Temp | -10°C~+50°C |
DVR Specification:
System | Model | AP-9604HV |
Main Processor | High performance embedded microprocessor HI3515 | |
Operating System | Embedded LINUX | |
System Resources | Pentaplex function:live,recording,playback,backup & remote access | |
User Interface | GUI,on-screen menu tips | |
Display | 1/4 | |
Video | Video Standards | PAL 625 line,50 f/s;NTSC 525 line,60 f/s |
Video Compression | H.264 main profile | |
Video Recording | D1:PAL 1f/s-25f/s NTSC 1f/s-30f/s | |
Encode capacity | 100/120fps(D1) | |
Motion Detection | Zones:192(16*12)detection zones | |
Audio | Audio Compression | G711A |
Bidrectional Talk | Support | |
Record & Playback | Recording Mode | Manual>Alarm>Video Detection>Continuous |
Playback | Multi channels playback simultaneously,pause,stop,rewind,fast play, slow play,next file,previous file,repeat,shuffle,backup selection | |
Search Mode | Time/Date,Alarm,Motion Detection & exact search(accurate to second) | |
Storage & Backup | Space Occupation | Audio 28.8MB/H ;Video 25~450 MB/H |
Record Storage | Local Hard disk and Network | |
Backup Mode | Network download/movable HDD | |
Interface | Video Input | 4channel |
Video Output | 1 channel TV output BNC,1.0Vp-p,75Ω,1 VGA output , | |
Audio Input | 4 channel | |
Audio Output | 1 channel | |
Alarm Input | N/A | |
Relay Output | N/A | |
Net Interface | RJ-45 (10M/100M) | |
PTZ Control | Support | |
USB Interface | 2 x USB2.0 | |
Hard Disk | 1SATA ports(Max 2048G) | |
Environmental | Power Supply | 12V/2A |
Power Consumption | <10W(not include Hard disk) | |
Working Temperature | 0°C-+55°C | |
Working Humidity | 10%-90% | |
Atmosphere Pressure | 86kpa-106kpa | |
Dimension | 325 x 48 x 255mm | |
Weight | 2.1kg |
More Hot Sale Products:
Application
Sunivision has CE & ROHS for both DVR & CCTV CAMERAS.
Sunivision Technology Development Co.,Ltd. is a leading and professional CCTV manufacturer located in Guangzhou,
China. Sunivision was established in 2008 ,with 2000 SQUARE METER factory and 150 employees including 5 R&D
engineers and 10 person for quality control,15% of the Year Sales Volume will be put into R&D,2-5 New Products will
be come out every month!
Sunivision specializes in researching, producing and exporting CCTV Analog Cameras, AHD Camera,
Digital camera(IP Camera,CVI Camera etc.)
and Stand-alone DVRs,CVI DVR ,AHD DVR,NVR, providing the most stable digital security solutions.
Teamwork Shows:
A. Prompt Reply
B. OEM&ODM:
- Printing logoon the camera;
- Customized camera housing;
- Customized package box
C. Fast Delivery:
2-7 working days for sample after payment cleared.
4-12 working days for medium & large order after payment cleared.
D. Payment
You can pay for order via T/T, Western Union, Paypal,L/C
E. Shipping
We have strong cooperation with DHL, TNT,UPS, Fedex.EMS. China Air post.sea
You aslo can choose you own shipping forwarder
F. After sale service:
- Any technologic problems and quality problems,you can contact us by email or by phone.
- We will do our best to help to sovle your any problems as soon as possible.
- Free repair within two years,except huma
G. Warranty:
- Free repair within two years,except human factors.
Q.May I print our company logo on package box and camera and DVR?
A:Of course,buyer logo is welcome in our company.We have one production line for printing buyer logo.
Q.Do you provide warranty for your products?
A:Yes,we promise two years warranty for all our products.
Q.What is your method of payment?
A:Pay via T/T,Western Union,Escrow,L/C is welcome.
Q.What is Minimum Order Quantity?
A:Minimum Order Quantity is 50pcs,but sample order is welcome.
