400w600w800w1200w1600w 48v 24v 12v mini wind turbine for home use

Name: 400w600w800w1200w1600w 48v 24v 12v mini wind turbine for home use
Brand: NEWSKY
Availability: InStock

FOB Price

USD $214 - $392 / Piece

1 Piece(Min.Order)

Supply Ability 5000 Piece / Pieces per Month
Port NINGBO
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shandong, China		Brand Name	NEWSKY
Model Number	MINI400-5PLUS		Type	Wind Power Generator

Product Description

Specifications

400w600w800w1200w1600w 48v 24v 12v mini wind turbine for home use
Bearing: Sweden SKF
CE ROHS

Product Description

400w 600w 800w 1200w 1600w

48v 24v 12v mini wind turbine for home use

Models

400W, 600W, 800W, 1200W, 1600W

Features

48v 24v 12v mini wind turbine for home use

♦ Bearing: Sweden SKF SKF

♦ Stainless steel screw bolt: Brand THE

♦ 100% Primary aluminum housing, not secondary aluminum

♦ Low start-up wind speed

♦ High-efficient Generator

♦ Perfect Wind Wheel System

♦ Unique Design Of The Rudder

♦ Damp-proof, sand-proof, Anti-rust, Anticorrosion

♦ Easy installation, Free of maintenance, Long lifespan over 15years

Specification

48v 24v 12v mini wind turbine for home use

400W

Model	MINI400W-3Plus	MINI400W-5Plus
Rated power	400 watts at 12 m/s
Max Capacity	450watts
Voltage	12, 24 VDC
Blades	3 Pcs Nylon Fiber	5 Pcs Nylon Fiber
Start-Up Wind Speed	2.0 ( m/s)	1.5 ( m/s)
Cut-In Wind Speed	2.5(m/s)	2.0(m.s)
Rotor Diameter	1.16 m	1.21m
Weight	6.2 kg	7.1 kg
Shipping Dimensions	790x 430x 220 mm (8 kg)	790x 430x 220 mm ( 9.3 kg)
KWH per Month	30KWh at 3.2 m/s	42KWh at 3.2 m/s
Mount	1.9 inch (48 mm) OD pipe
Turbine Controller (Plus)	Microprocessor-based smart internal regulator with Maximum Power Point Tracking,MPPT
Body	Cast aluminum
Overspeed Protection	Electronic torque control
Working temperature	—40℃~ 150℃
Certificate	ISO9001:2008 ,CE, Rohs
Survival Wind Speed	50 m/s
Warranty	3 year limited warranty

Specification

48v 24v 12v mini wind turbine for home use

600W,800W,1200W,1600W

Model	MAX 600W	MAX 800W	MAX 1200W	MAX 1600W
Rated power	600W	800W	1200W	1600W
Max power	750W	950W	1300W	1800W
Rated voltage	24 VDC	48 VDC	48VDC/110VDC	48VDC/110VDC
Rated current	25A	16.7A	25A/10.9A	33A/14.5A
Rated Rpm	650
Rated wind speed	12m/s
Blades	5 Pcs Nylon Fiber glass
Start-Up Wind Speed	1.5 ( m/s)	1.5 ( m/s)	2.0 ( m/s)	2.0 ( m/s)
Cut-In Wind Speed	2.0 (m/s)	2.0 (m/s)	2.5 (m/s)	2.5 (m.s)
Rotor Diameter	1.7 m	1.8 m	2.0 m	2.2 m
N.W	28.5KG	30KG	36KG	41KG
G.W	33KG	35.5KG	41KG	46KG
Shipping Dimensions	1690540290mm	1690540290mm	1890540290mm	1890540290mm
Mount	Flange connection
Turbine Controller	MPPT wind solar hybrid controller
Body	Cast aluminum
Overspeed Protection	Electromagnetic & blade aerodynamic braking
Working temperature	—40℃~ 150℃
Certificate	ISO9001:2008 ,CE, Rohs
Survival Wind Speed	50 m/s
Warranty	3 year limited warranty

Projects Show

48v 24v 12v mini wind turbine for home use

are windly used for home use,marine,hybrid power system,communication project...etc

Packaging & Shipping

48v 24v 12v mini wind turbine for home use

Model	MINI400W-3PLUS	MINI400W-5PLUS
Weight	6.2 kg	7.1 kg
Shipping Dimensions	790x 430x 220 mm (8 kg)	790x 430x 220 mm ( 9.3 kg)
KWH per Month	30KWh at 3.2 m/s	42KWh at 3.2 m/s
Mount	1.9 inch (48 mm) OD pipe
Warranty	3 year limited warranty
packing	Cartons for exporting with EPE protection

Our Services

Factory Show

48v 24v 12v mini wind turbine for home use

Certifications

48v 24v 12v mini wind turbine for home use

---------------------------------------------------------------

Why choose us?

1.Partner of F.A.O.
2.Serving wind&solar products for more than 6 years.
3.Specialized in the series of products supporting services.
4. Quality is the first.

---------------------------------------------------------------
