Specifications
1.Compressed air operation2.Sand blasting room
3.Competitive price
4.Promote delivery
5. Suitable for big metal fabrication
Qingdao Antai Heavy Industry Machinery Co., Ltd.
Founded in 2003, 10 years experience for making shot blasting machine.
A group company,having real estate, machinery and leather bags industry.
Eight experienced engineers to consider every possibility for customers.
Three of them has over 25 years knowledge of shot blasting technology.
3D software for auxiliary design. Show every design details in front of you.
Experienced technicians for production, installation, commissioning & service.
ISO 9001:2008 certified company, CE certificate will be issued soon.
All machining parts out sourced from professional CNC machining company with strict quality control procedure.
Own foundry to produce special material spare parts for our machines.
Air sand blast machine Introduction:
Air sand blasting room uses a trolley which cannot rotate to load the work parts and move in and out of the blast room. Operator should hold an air blast gun to clean the work parts in the blast room. The abrasive will be circulated by air pressure circulation system, and separated by cyclone separator. This machine doesn’t need screw conveyor, belt conveyor and bucket elevator any more because of using waffle floor, taper hopper and air pressure conveying method. It can highly reduce production cost, and it has been widely used.
Technical Specification of air blast machine:
Model: QV60
1. Workpiece weight: 500 kg
2. Dia. of rotary trolley: φ1500 mm
3. Abrasive flow rate: 20 m3/h
4. Blast gun quantity: 1 pcs
5. Power of compressor: 45KW
6. Ventilation: 11000 m3/h
7. Outline dimension: 2000*1900*2000 mm
Model: QV60
1. Workpiece weight: 20000 Kg
2. Abrasive flow of single blast gun: 1750-2000 kg/h
3. Blast gun quantity: 2 pcs
4. Air consumption of single blast gun: 6.1 m3/h
5. Working pressure: 0.6-0.8 Mpa
6. Total power: 60 Kw
7. Ventilation capacity: 23000 m3/h
