shot blasting machine
Q37 series Hanger spinner hook shot blasting machine can be used for light industrial machinery, construction machinery, engineering machinery, mining machinery, pressure vessels, automobiles, shipbuilding, construction, chemical, electrical, small and medium industries such as machine tool castings, steel plates, aluminum and other plates of the surface cleaning or strengthened, Hanger spinner hook shot blasting machine used to enhance product quality and the appearance of parts of the surface state.
Continuous hook shot blasting machine Particularly suited to:
1.Hanger spinner hook shot blasting machine suite to multiline varieties, small quantizes of castings, forgings and steel parts for surface cleaning and enhancement to remove the work piece surface of a small amount of viscous-sand, sand core and oxidative skin.
2.Hanger spinner hook shot blasting machine suited to heat treatment on the surface clean-up and enhancement. Right inappropriate collision slender, thin-walled parts cleaning.
3.Hanger spinner hook shot blasting machine applies equally to clean up parts special tooling will be disassembled into liquidation conducted peen, such as aluminum alloy wheels, round or square billet, bar, and the work piece to clean the work piece size adjustable section, the number and angle of peen layout through computer simulation, uniform cleaning effect.
Continuous hook shot blasting machine Technical parameters:
Item |
Unit |
Q376 |
Q376B |
Q378C |
Q3710 |
Q3720 |
Q3730 |
Q3750 |
Q37100 |
Maximum weight of cleaning |
Kg |
500 |
600 |
800 |
1000 |
2000 |
3000 |
5000 |
10000 |
Abrasive flow rate |
Kg/min |
2*200 |
2*200 |
2*250 |
2*250 |
3*250 |
3*250 |
4*250 |
5*250 |
Ventilation capacity |
m3/h |
5000 |
5000 |
5000 |
5000 |
9000 |
11000 |
14000 |
16000 |
Lifting amount of elevating conveyor |
T/H |
24 |
24 |
30 |
30 |
45 |
45 |
60 |
75 |
Separating amount of separator |
T/H |
24 |
24 |
30 |
30 |
45 |
45 |
60 |
75 |
Max overall dimensions of suspender |
mm |
Ø600 *1200 |
Ø700 *1200 |
Ø1000 *1600 |
Ø1200 *1800 |
Ø1400 *2200 |
Ø1600 *2300 |
Ø1800 *2500 |
Ø3000 *3000 |
♦ Founded in 2003, 10 years experience for making shot blasting machine.
♦ A group company,having real estate, machinery and leather bags industry.
♦ Eight experienced engineers to consider every possibility for customers.
♦ Three of them has over 25 years knowledge of shot blasting technology.
♦ 3D software for auxiliary design. Show every design details in front of you.
♦ Experienced technicians for production, installation, commissioning & service.
♦ ISO 9001:2008 certified company, CE certificate will be issued soon.
♦ All machining parts out sourced from professional CNC machining company with strict quality control procedure.
♦ Own foundry to produce special material spare parts for our machines.
